▶ EngineEngine Manufacturer AGCO Power FPT Engine Model 44 AWFC F5G Engine Type 4-cylinder, intercooled turbocharged diesel Dual Command: 4-cylinder diesel; Electro Command: 4-cylinder, turbocharged and intercooled, common-rail diesel No. of Cylinders 4 4 Displacement 268.5 in³ 207 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 120 hp 117 hp PTO Power 99 hp Dual Command: 100 hp; Electro Command: 99 hp Engine Emissions Constraints Tier 4 Tier 4B/Final Cooling System Type Liquid cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System High-pressure common-rail direct injection (HPCR) Electro Command: high-pressure common-rail, electronic fuel delivery control Alternator 80 A, 12 V 120 A ▶ HydraulicsPump Type Two high-pressure gear pumps Fixed displacement, tandem pumps (implement and steering) Implement Flow 15.1 gpm Dual Command: 16.9 gpm; Electro Command: 21.1 gpm Steering Flow Not Published Dual Command: 9.7 gpm; Electro Command: 11.4 gpm Total Hydraulic Flow 25.9 gpm Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Overall Hydraulic Pump Flow Not Published Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 26 gpm Not Published No. of Standard Remote Valves 2 Dual Command: 2 or 3; Electro Command: 2 No. of Optional Remote Valves 3rd valve optional Electro Command: 3 mechanical rear; mid-mount: 2 Function Mechanical or 2 Function Electronic ▶ Fluid CapacityFuel Tank Capacity 38.3 gal Electro Command: 43.6 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement via switch Independent (hydraulic wet disc clutch) PTO Rear 540 / 540E / 1000 rpm Dual Command: 540/1000 rpm (optional); Electro Command: 540/1000 rpm (540/540E/1000 optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 9,390 lb Dual Command: 5,620 lb (7,351 lb with optional ram) Lift Control Type Electronic linkage control (ELC) Not Published ▶ Transmission & DrivetrainTransmission Type 12F x 12R, 2-range power shuttle with electrohydraulic shuttle lever Dual Command: 24x24 Hi-Lo with power shuttle (standard); Electro Command: 16x16 semi-powershift (auto-shift or 32x32 creeper optional) No. of Speeds 12 forward, 12 reverse Dual Command: 24F/24R; Electro Command: 16F/16R (32F/32R with creeper) Max Travel Speed (Forward) 25 mph 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Wet clutch with easy shift knob and electrohydraulic power shuttle lever Not Published Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock (rocker switch); hydraulic front differential lock on 4WD TerraLock automatic 4WD engagement and differential lock system (optional on Electro Command) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Cab: tilt and telescopic steering; platform: tilt steering Power steering Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Hydraulic wet disc Seat Suspension & Adjustability Cab: air-suspension swivel seat; platform: mechanical spring-suspension seat with armrests Not Published Front Axle Type Heavy-duty 4WD front axle 4WD front axle, Class 1.5 HD; TerraGlide suspended front axle optional on Electro Command Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 64.8 in Dual Command: 75.7 in Wheelbase 98.4 in Dual Command: 89.9 in; Electro Command: 93.7 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Dual Command: 106.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Dual Command: 102.1 in; Electro Command: 107 in Overall Length Not Published Dual Command: 160.9 in; Electro Command: 165 in ▶ WeightTractor Weight (Base) 4WD ROPS: 9,371 lb; 4WD Cab: 10,187 lb Dual Command (ROPS): 7,672 lb; Dual Command (Cab): 8,157 lb; Electro Command (shipping weight, less ballast): 10,031 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 460/85R34 standard radial Not Published R1 Agricultural - Front Not Published 14.9R24 R1 Agricultural - Rear Not Published 18.4R34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer style or European style attachment system Loader Model 941X; 946X; FL.3723; FL.3819 810LA (NSL); 815LA (MSL) Loader Lift Height 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in 825TL: 139.0 in; 835TL: 146.9 in (to pivot pin) Loader Lift Capacity (Full Height) 941X: 2,220 lb; FL.3723: 2,840 lb (to full height) 825TL NSL: 2,954 lb; 825TL MSL: 3,086 lb; 835TL NSL: 3,638 lb; 835TL MSL: 3,836 lb (to max height, measured 31.5 in forward of pivot pin) Loader Breakout Force FL.3723: 5,819 lb; FL.3819: 4,893 lb 825TL NSL: 3,109 lb; 825TL MSL: 3,417 lb; 835TL NSL: 3,880 lb; 835TL MSL: 4,277 lb (measured 31.5 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
