▶ EngineEngine Manufacturer Iseki Kubota Engine Model Not Published D902 Engine Type 3-cylinder, liquid-cooled diesel Liquid-cooled, 3-cylinder diesel No. of Cylinders 3 3 Displacement 68.5 in³ 54.8 in³ Rated Engine Speed 2600 rpm 3200 rpm Engine Power (Gross) 22.5 hp 23 hp PTO Power 18.7 hp 17.7 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Not Published Indirect injection Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 4.3 gpm Not Published Steering Flow 2 gpm Not Published Total Hydraulic Flow 6.3 gpm 6.3 gpm Overall Hydraulic Pump Flow Not Published 6.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity Not Published 2.8 qt Crankcase Capacity Not Published 3.3 qt Transmission / Hydraulic System Capacity Not Published 3.06 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Live independent, wet hydraulic clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Independent, 2000 rpm Standard mid-PTO, 2500 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,190 lb 1210 lb Hitch Lift Capacity (at 24”) Not Published 670 lb Lift Control Type Rate of drop control (standard) Directional control with auto-return lever ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic with side-by-side foot pedals and cruise control Hydrostatic transmission with High-Low gear shift, 2-range No. of Speeds Infinite forward and reverse (2-range hydrostatic) 2-range Max Travel Speed (Forward) 9.1 mph (with R1 tires) 8.4 mph Max Travel Speed (Reverse) Not Published 6.2 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post ROPS (foldable ROPS on BX25 only) Steering Power steering Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Coil spring seat; retractable seat belt Not Published Front Axle Type 4WD front axle Selectable 2WD and 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 97.6 in 95.5 in Overall Width 47.25 in 44.5 in Wheelbase 57.1 in 55.1 in Ground Clearance 6.7 in 8.7 in Min. Turn Radius without Brakes Not Published 7.5 ft Height to Top of ROPS 72.8 in 70.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,433 lb 1322 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, turf or industrial: front 18x8.50-10, rear 26x12.00-12 Turf, bar (ag) or industrial: 18x8.5-10 front, 26x12-12 rear R1 Agricultural - Front 18x8.50-10 18x8.5-10 R1 Agricultural - Rear 26x12.00-12 26x12-12 R3 Turf - Front 18x8.50-10 18x8.5-10 R3 Turf - Rear 26x12.00-12 26x12-12 R4 Industrial - Front 18x8.50-10 18x8.5-10 R4 Industrial - Rear 26x12.00-12 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System DL95: pin-on (factory or dealer installation) Not Published Loader Model DL95 LA243 Loader Lift Height DL95: 72.8 in LA243: 71.3 in Loader Lift Capacity (Full Height) DL95: 870 lb LA243: 750 lb Loader Breakout Force DL95: 920 lb LA243: 1415 lbf ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
