▶ EngineEngine Manufacturer Iseki Shibaura Engine Model Not Published N843T-F Engine Type 3-cylinder, liquid-cooled diesel 3-cylinder diesel, liquid-cooled No. of Cylinders 3 3 Displacement 68.5 in³ 91.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 22.5 hp 24 hp PTO Power 18.7 hp 19.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Not Published Indirect low-pressure injection Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Gear-type pump Implement Flow 4.3 gpm Not Published Steering Flow 2 gpm 3.8 gpm Total Hydraulic Flow 6.3 gpm 10.5 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 6.7 gpm No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to 2 ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 10.0 gal Coolant Capacity Not Published 1.32 gal Crankcase Capacity Not Published 1.22 gal Transmission / Hydraulic System Capacity Not Published 10.04 gal Front Axle Fluid Capacity Not Published 1.48 gal ▶ PTO & HitchPTO Type Independent Transmission driven PTO Rear 540 rpm 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Independent, 2000 rpm Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,190 lb 2,205 lb Hitch Lift Capacity (at 24”) Not Published 1,600 lb Lift Control Type Rate of drop control (standard) Not Published ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic with side-by-side foot pedals and cruise control 9 x 3 mechanical shift constant mesh gears or 3-range hydrostatic No. of Speeds Infinite forward and reverse (2-range hydrostatic) Gear: 9F / 3R; HST: 3-range infinite Max Travel Speed (Forward) 9.1 mph (with R1 tires) Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Gear: dry single disc Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical engagement via heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Internal wet brakes, single brake pedal on HST, two brake pedals on gear models Seat Suspension & Adjustability Coil spring seat, reversible; retractable seat belt Suspended vinyl seat with retractable seatbelt, fixed steering wheel Front Axle Type 4WD front axle Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 177 in (without 3-point hitch) 116.0 in (w/o 3-point linkage) (without 3-point hitch) Overall Width 53.94 in 52.4 in Wheelbase 57.1 in 65.9 in Ground Clearance 6.7 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 86 in 97.6 in Height to Top of ROPS (folded) Not Published 63.8 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) Not Published HST: 2,657 lb Weight with ROPS and Loader 2,670 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, turf or industrial: front 18x8.50-10, rear 26x12.00-12 Not Published R1 Agricultural - Front 18x8.50-10 Not Published R1 Agricultural - Rear 26x12.00-12 Not Published R3 Turf - Front 18x8.50-10 Not Published R3 Turf - Rear 26x12.00-12 Not Published R4 Industrial - Front 18x8.50-10 Not Published R4 Industrial - Rear 26x12.00-12 Not Published ▶ Loader & AttachmentsQuick Attach Loader System DL95: pin-on (factory or dealer installation) L105E: skid steer or pin-type implement attachments Loader Model DL95 L105E Loader Lift Height DL95: 72.8 in L105E: 95.7 in Loader Lift Capacity (Full Height) DL95: 870 lb L105E: 1,210 lb Loader Breakout Force DL95: 920 lb L105E: 1,460 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year powertrain warranty
