▶ EngineEngine Manufacturer Iseki Kubota Engine Model E3112 D902 Engine Type 3-cylinder, liquid-cooled diesel Liquid-cooled, 3-cylinder diesel No. of Cylinders 3 3 Displacement 68.5 in³ 54.8 in³ Rated Engine Speed 2600 rpm 3200 rpm Engine Power (Gross) 22.5 hp 23 hp PTO Power 18.3 hp 17.7 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Not Published Fuel System Indirect injection Not Published Alternator 40 A Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 4.3 gpm Not Published Steering Flow 2.0 gpm Not Published Total Hydraulic Flow 6.3 gpm Not Published Overall Hydraulic Pump Flow Not Published 6.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity 1.23 gal 2.8 qt Crankcase Capacity 0.68 gal 3.3 qt Transmission / Hydraulic System Capacity 2.9 gal Not Published Front Axle Fluid Capacity 1.05 gal Not Published ▶ PTO & HitchPTO Type Independent Live independent, wet hydraulic clutch PTO Rear 540 rpm (1.375 in, six spline) 540 rpm Mid-PTO Availability Independent, 2000 rpm (1 in, fifteen spline) Standard mid-PTO, 2500 rpm Category, 3-Point Hitch Category I Category I (optional) Hitch Lift Capacity 1,191 lb Not Published Hitch Lift Capacity (at 24”) 661 lb 680 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic with side-by-side foot pedals and cruise control Not Published No. of Speeds Infinite forward and reverse (2-range hydrostatic) Not Published Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Locking rear differential (4WD) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Foldable ROPS Steering Power steering Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD front axle Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 551 lb ▶ Dimensions & ManeuverabilityOverall Width 46.7 in (minimum width, with R1 tires) 44.5 in (with turf tires) Wheelbase 57.1 in 55.1 in Ground Clearance 6.7 in 8.7 in (front axle) Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 72.8 in 87.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 97.6 in 95.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,521 lb 1,587 lb Weight with ROPS and Loader Not Published 2,475 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options AG, Turf or R4 Industrial: front 18x8.50-10, rear 26x12.00-12 18x8.5-10 front, 26x12-12 rear (Turf/Industrial) R1 Agricultural - Front 18x8.50-10 Not Published R1 Agricultural - Rear 26x12.00-12 Not Published R3 Turf - Front 18x8.50-10 Not Published R3 Turf - Rear 26x12.00-12 Not Published R4 Industrial - Front 18x8.50-10 18x8.5-10 R4 Industrial - Rear 26x12.00-12 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer quick attach LA240A loader (4-point mounting, no tools required) Loader Model FL1805 LA240A Loader Lift Height 74 in LA240A: 71.3 in (at pivot pin) Loader Lift Capacity (Full Height) 922 lb LA240A: 745 lb (at pivot pin, max. height) Loader Breakout Force 1,392 lb LA240A: 992 lbf ▶ WarrantyWarranty Length & Coverage Five-year powertrain warranty Not Published
