▶ EngineEngine Manufacturer Iseki Iseki Engine Model E3112 E3112 Engine Type 3-cylinder, liquid-cooled diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 68.5 in³ 68.5 in³ Rated Engine Speed 2600 rpm 3000 rpm Engine Power (Gross) 22.5 hp 24.5 hp PTO Power 18.3 hp 19.6 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System Indirect injection Indirect injection Alternator 40 A 40 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 4.3 gpm 4.9 gpm Steering Flow 2.0 gpm 2.0 gpm Total Hydraulic Flow 6.3 gpm 6.8 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity 1.23 gal 1.23 gal Crankcase Capacity 0.68 gal 0.68 gal Transmission / Hydraulic System Capacity 2.9 gal 2.9 gal Front Axle Fluid Capacity 1.05 gal 1.05 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm (1.375 in, six spline) 540 rpm (1.375 in, six spline) Mid-PTO Availability Independent, 2000 rpm (1 in, fifteen spline) Independent, 2000 rpm (1 in, fifteen spline) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,191 lb 1,191 lb Hitch Lift Capacity (at 24”) 661 lb 661 lb Lift Control Type Not Published Not Published ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic with side-by-side foot pedals and cruise control 2-range hydrostatic with side-by-side foot pedals and cruise control No. of Speeds Infinite forward and reverse (2-range hydrostatic) Infinite forward and reverse (2-range hydrostatic) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Locking rear differential (4WD) Locking rear differential (4WD) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD front axle 4WD front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 46.7 in (minimum width, with R1 tires) 46.7 in (minimum width, with R1 tires) Wheelbase 57.1 in 57.1 in Ground Clearance 6.7 in 6.7 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 72.8 in 72.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 97.6 in 97.6 in ▶ WeightTractor Weight (Base) 1,521 lb 1,532 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options AG, Turf or R4 Industrial: front 18x8.50-10, rear 26x12.00-12 AG, Turf or R4 Industrial: front 18x8.50-10, rear 26x12.00-12 R1 Agricultural - Front 18x8.50-10 18x8.50-10 R1 Agricultural - Rear 26x12.00-12 26x12.00-12 R3 Turf - Front 18x8.50-10 18x8.50-10 R3 Turf - Rear 26x12.00-12 26x12.00-12 R4 Industrial - Front 18x8.50-10 18x8.50-10 R4 Industrial - Rear 26x12.00-12 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer quick attach Skid steer quick attach Loader Model FL1805 FL1805 Loader Lift Height 74 in 74 in Loader Lift Capacity (Full Height) 922 lb 922 lb Loader Breakout Force 1,392 lb 1,392 lb ▶ WarrantyWarranty Length & Coverage Five-year powertrain warranty Five-year powertrain warranty
