▶ EngineEngine Manufacturer Iseki Iseki Engine Model E3112 E3CD Engine Type 3-cylinder, liquid-cooled diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 68.5 in³ 91.4 in³ Rated Engine Speed 3000 rpm 2600 rpm Engine Power (Gross) 24.5 hp 24.8 hp PTO Power 19.6 hp 20.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry Not Published Fuel System Indirect injection Not Published Alternator 40 A Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 4.9 gpm 5.5 gpm Steering Flow 2.0 gpm 3.2 gpm Total Hydraulic Flow 6.8 gpm 8.7 gpm Overall Hydraulic Pump Flow Not Published 8.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 5.5 gpm No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 7.1 gal Coolant Capacity 1.23 gal Not Published Crankcase Capacity 0.68 gal Not Published Transmission / Hydraulic System Capacity 2.9 gal Not Published Front Axle Fluid Capacity 1.05 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm (1.375 in, six spline) 540 rpm Mid-PTO Availability Independent, 2000 rpm (1 in, fifteen spline) Independent, 2000 rpm (optional) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,191 lb 1,322 lb Hitch Lift Capacity (at 24”) 661 lb 992 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic with side-by-side foot pedals and cruise control Hydrostatic No. of Speeds Infinite forward and reverse (2-range hydrostatic) 3 hydrostatic ranges with cruise Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Locking rear differential (4WD) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Wet, multiple disc Seat Suspension & Adjustability Not Published Adjustable mechanical suspension Front Axle Type 4WD front axle Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 46.7 in (minimum width, with R1 tires) 55.1 in Wheelbase 57.1 in 61.4 in Ground Clearance 6.7 in 11.6 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 72.8 in 96.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 97.6 in 111 in ▶ WeightTractor Weight (Base) 1,532 lb 2,077 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options AG, Turf or R4 Industrial: front 18x8.50-10, rear 26x12.00-12 R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 18x8.50-10 7-12 R1 Agricultural - Rear 26x12.00-12 35x12.00-16.5 or 9.5-16 R3 Turf - Front 18x8.50-10 25x8.50-14 R3 Turf - Rear 26x12.00-12 36x13.50-15 R4 Industrial - Front 18x8.50-10 25x8.50-14 R4 Industrial - Rear 26x12.00-12 14-17 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer quick attach Not Published Loader Model FL1805 FLx2106 Loader Lift Height 74 in FLx2106: 83 in (at pivot pin) Loader Lift Capacity (Full Height) 922 lb FLx2106: 852 lb (to full height, at 19.5 in forward of pivot pin) Loader Breakout Force 1,392 lb FLx2106: 1,282 lb (at 19.5 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Five-year powertrain warranty Not Published
