▶ EngineEngine Manufacturer Shibaura Kubota Engine Model Not Published D1803-CR-E5 Engine Type 3-cylinder turbocharged diesel, liquid-cooled Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 3 3 Displacement 91.3 in³ 111.4 in³ Rated Engine Speed 2800 rpm 2700 rpm Engine Power (Gross) 38.5 hp 37.5 hp PTO Power 32.7 hp 30.3 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry Dry type, single element Fuel System Not Published Direct injection Alternator Not Published 45 A, 12 V ▶ HydraulicsPump Type Dual engine-driven gear pumps Not Published Implement Flow 7.5 gpm 6.3 gpm Steering Flow Not Published 3.8 gpm Total Hydraulic Flow 10.4 gpm 10.1 gpm (6.3 + 3.8, computed) Overall Hydraulic Pump Flow Not Published 10.1 gpm (6.3 + 3.8, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Up to 2 Not Published No. of Optional Remote Valves 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 11.1 gal Coolant Capacity Not Published 6.3 qt Crankcase Capacity Not Published 7.1 qt Transmission / Hydraulic System Capacity Not Published 6.9 gal Front Axle Fluid Capacity Not Published 4.8 qt ▶ PTO & HitchPTO Type 8x8 Synchro Shuttle: independent; HST: transmission driven Live independent PTO with hydraulic clutch PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I SAE Category I Hitch Lift Capacity 2,205 lb 1998 lb Hitch Lift Capacity (at 24”) 1,598 lb 1435 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 8 x 8 synchro shuttle or 3-range hydrostatic Hydrostatic transmission (3-range) No. of Speeds 8x8 Synchro Shuttle: 8F / 8R; HST: 3-range infinite 3-range Max Travel Speed (Forward) Not Published 14.1 mph Max Travel Speed (Reverse) Not Published 12.7 mph Clutch Not Published Not Applicable Differential Lock & Limited Slip Options Mechanical rear differential lock Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Integral type power steering Brakes Wet disc Mechanical, wet disc type Seat Suspension & Adjustability Not Published Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Not Published Cast-iron front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 730 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 121.1 in 108.5 in (without 3-point hitch) Overall Width 56.1-59.4 in 55.1 in Wheelbase 65.9 in 63.4 in Ground Clearance Not Published 13.4 in Min. Turn Radius without Brakes Not Published 8.2 ft (with brake applied) Height to Top of ROPS 93.9-94.5 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) Not Published 2778 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 7-16 7.2-16 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front Not Published 25X8.50-14 R3 Turf - Rear Not Published 13.6-16 R4 Industrial - Front 27x8.50-15 27X8.50-15 R4 Industrial - Rear 15-19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System FLx2407: pin-on (skid steer quick attach optional) Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Loader Model FLx2407 LA526 Loader Lift Height FLx2407: 94.3 in 94.8 in Loader Lift Capacity (Full Height) FLx2407: 1,450 lb 1144.4 lb Loader Breakout Force FLx2407: 2,288 lb Not Published ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
