▶ EngineEngine Manufacturer Shibaura LS Mtron Engine Model N3LDI-T L3C19-T Engine Type 3-cylinder turbocharged intercooled diesel, liquid-cooled Vertical, water-cooled, 4 cycle diesel No. of Cylinders 3 3 Displacement 101.4 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power 31.2 hp 32 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry Dry Fuel System Common rail direct injection CRDI Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Engine-driven gear-type pump Gear pump, engine drive Implement Flow Not Published 8.2 gpm Steering Flow Not Published 5.5 gpm Total Hydraulic Flow Not Published 13.7 gpm Overall Hydraulic Pump Flow 12.6 gpm 13.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 12.1 gpm Not Published No. of Standard Remote Valves Cab: 1 pair Not Published No. of Optional Remote Valves Up to 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 10.56 gal 12.4 gal Coolant Capacity 6.34 qt Not Published Crankcase Capacity 4.86 qt Not Published Transmission / Hydraulic System Capacity 12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal Not Published Front Axle Fluid Capacity 7.9 qt Not Published ▶ PTO & HitchPTO Type Independent, with soft-start feature Independent PTO Rear 540 rpm (6-spline) 540 rpm Mid-PTO Availability Optional, 2,000 rpm Optional (2,000 rpm) Category, 3-Point Hitch Category I with extendable ball ends Category I Hitch Lift Capacity Not Published 1,808 lb Hitch Lift Capacity (at 24”) 2,535 lb Not Published Lift Control Type Draft control optional Position & Draft ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic Hydrostatic (HST) No. of Speeds 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite 3 ranges (HST) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Single stage dry type Not Published Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Power Steering Brakes Internal wet disc brakes, independent foot pedals Wet, Multi-disc Seat Suspension & Adjustability Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Not Published Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 64.2 in Not Published Wheelbase 69.7 in 69 in Ground Clearance 15.4 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 99.2 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.3 in 86.6 in Overall Length 122.0 in 128.3 in (frame to link) ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb 3,661 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, Snow Ag, Industrial, Turf R1 Agricultural - Front 8-16 7-14 R1 Agricultural - Rear 12.4x24 11.2-24 R3 Turf - Front 27x8.50-15 25x8.5-14 R3 Turf - Rear 41x14.00-20 41x14-20 R4 Industrial - Front 10-16.5 25x8.5-14 R4 Industrial - Rear 17.5L-24 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System DL125: Pin-on (skid steer quick attach optional) LL3116 Loader Model DL125 Not Published Loader Lift Height DL125: 106 in (at pivot pin) Not Published Loader Lift Capacity (Full Height) DL125: 1,660 lb (at pivot pin, full height) LL3116: 2,185 lb Loader Breakout Force DL125: 3,000 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Five-year powertrain warranty 6-year limited powertrain warranty
