▶ EngineEngine Manufacturer Shibaura LS Engine Model N3LDI-T L3C19-T4 Engine Type 3-cylinder turbocharged intercooled diesel, liquid-cooled 3-cylinder, liquid-cooled, diesel, turbocharged (TC), CRDI No. of Cylinders 3 3 Displacement 101.4 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power 31.2 hp 34 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System Common rail direct injection CRDI (Delphi common rail direct injection) Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Engine-driven gear-type pump Gear pump, engine driven Implement Flow Not Published 8.2 gpm Steering Flow Not Published 4.1 gpm Total Hydraulic Flow Not Published 12.3 gpm Overall Hydraulic Pump Flow 12.6 gpm 12.3 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow 12.1 gpm Not Published No. of Standard Remote Valves Cab: 1 pair None No. of Optional Remote Valves Up to 3 1 or 2 pairs (optional) ▶ Fluid CapacityFuel Tank Capacity 10.56 gal 7.4 gal Coolant Capacity 6.34 qt 1.9 gal Crankcase Capacity 4.86 qt 1.5 gal Transmission / Hydraulic System Capacity 12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal 8.5 gal Front Axle Fluid Capacity 7.9 qt 1.7 gal ▶ PTO & HitchPTO Type Independent, with soft-start feature Independent (wet disc clutch) PTO Rear 540 rpm (6-spline) Standard (540 rpm) Mid-PTO Availability Optional, 2,000 rpm Optional (2,000 rpm) Category, 3-Point Hitch Category I with extendable ball ends Category I Hitch Lift Capacity Not Published 1,808 lb Hitch Lift Capacity (at 24”) 2,535 lb 1,433 lb Lift Control Type Draft control optional Position control ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic Synchro Shuttle No. of Speeds 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite F12 x R12 Max Travel Speed (Forward) Not Published 14.33 mph Max Travel Speed (Reverse) Not Published 13.63 mph Clutch Single stage dry type Dry single clutch Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Internal wet disc brakes, independent foot pedals Wet, multi-disc Seat Suspension & Adjustability Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Not Published Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 64.2 in 54 in Wheelbase 69.7 in 69 in Ground Clearance 15.4 in Not Published Min. Turn Radius without Brakes Not Published 10.79 ft (left); 11.02 ft (right) Height to Top of ROPS 99.2 in 88 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.3 in Not Published Overall Length 122.0 in 121 in (frame to link) ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb 2,881 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, Snow Ag, industrial or turf tires at no additional cost R1 Agricultural - Front 8-16 7-14 R1 Agricultural - Rear 12.4x24 11.2-24 R3 Turf - Front 27x8.50-15 25x8.50-14 R3 Turf - Rear 41x14.00-20 41x14-20 R4 Industrial - Front 10-16.5 27x8.50-14 R4 Industrial - Rear 17.5L-24 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System DL125: Pin-on (skid steer quick attach optional) Not Published Loader Model DL125 LL3302 Loader Lift Height DL125: 106 in (at pivot pin) LL3302: 94 in Loader Lift Capacity (Full Height) DL125: 1,660 lb (at pivot pin, full height) LL3302: 2,153 lb (at pivot pin, full height) Loader Breakout Force DL125: 3,000 lb (at pivot pin) LL3302: 3,579 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Five-year powertrain warranty 6-year limited warranty
