▶ EngineEngine Manufacturer Shibaura LS Mtron Engine Model N3LDI-T L3C19-T4 Engine Type 3-cylinder turbocharged intercooled diesel, liquid-cooled 4-stroke, vertical, water cooling, CRDI No. of Cylinders 3 3 Displacement 101.4 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power 31.2 hp 34.4 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry Dry Fuel System Common rail direct injection Delphi CRDI (Common Rail Direct Injection) Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Engine-driven gear-type pump Gear pump type, engine drive Implement Flow Not Published 8.2 gpm Steering Flow Not Published 4.1 gpm (mechanical); 5.5 gpm (HST) Total Hydraulic Flow Not Published 12.3 gpm Overall Hydraulic Pump Flow 12.6 gpm Not Published Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow 12.1 gpm Not Published No. of Standard Remote Valves Cab: 1 pair 2 pairs No. of Optional Remote Valves Up to 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 10.56 gal 10.6 gal (roll-bar); 12.4 gal (cabin) Coolant Capacity 6.34 qt 2.3 gal Crankcase Capacity 4.86 qt 1.6 gal Transmission / Hydraulic System Capacity 12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal 11.4 gal Front Axle Fluid Capacity 7.9 qt 2.1 gal ▶ PTO & HitchPTO Type Independent, with soft-start feature Independent PTO with wet disk clutch PTO Rear 540 rpm (6-spline) 540 (standard); 540 / 750 / 1,000 (optional 3-speed) Mid-PTO Availability Optional, 2,000 rpm Optional, 2000 rpm Category, 3-Point Hitch Category I with extendable ball ends Category I Hitch Lift Capacity Not Published 2,756 lb Hitch Lift Capacity (at 24”) 2,535 lb 2,469 lb Lift Control Type Draft control optional Position and draft control ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic Synchro-shuttle (mechanical) No. of Speeds 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite F16 x R16 (F32 x R16 with creeper, optional) Max Travel Speed (Forward) Not Published 16.8 mph Max Travel Speed (Reverse) Not Published 15.3 mph Clutch Single stage dry type Dry single clutch (mechanical only) Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Mechanical pedal type differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Brakes Internal wet disc brakes, independent foot pedals Wet, multi-disc Seat Suspension & Adjustability Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Not Published Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 64.2 in 62.5 in Wheelbase 69.7 in 73.2 in Ground Clearance 15.4 in Not Published Min. Turn Radius without Brakes Not Published 9.5 ft (with brake applied) Height to Top of ROPS 99.2 in 93 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.3 in 88.1 in Overall Length 122.0 in 133 in (bumper to link) ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb Roll-bar: 3,770 lb; Cabin: 4,210 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, Snow Ag 9.5-16 / 13.6-24; Turf 28x8.5-15 / 41x14-20; Industrial 12-16.5 / 17.5L-24 R1 Agricultural - Front 8-16 9.5-16 (6PR) R1 Agricultural - Rear 12.4x24 13.6-24 (8PR) R3 Turf - Front 27x8.50-15 28x8.5-15 R3 Turf - Rear 41x14.00-20 41x14-20 R4 Industrial - Front 10-16.5 12-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System DL125: Pin-on (skid steer quick attach optional) Not Published Loader Model DL125 LL4104 Loader Lift Height DL125: 106 in (at pivot pin) LL4104: 96.3 in Loader Lift Capacity (Full Height) DL125: 1,660 lb (at pivot pin, full height) LL4104: 2,713 lb (at pivot pin) Loader Breakout Force DL125: 3,000 lb (at pivot pin) LL4104: 3,802 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Five-year powertrain warranty General: 2 years or 750 hours (whichever occurs first). Extended powertrain: 6 years or 1,500 hours (whichever occurs first), for tractors retailed after January 1, 2017
