▶ EngineEngine Manufacturer Shibaura LS Mtron Engine Model N3LDI-T L3CRV-T4 Engine Type 3-cylinder turbocharged intercooled diesel, liquid-cooled 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 101.4 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power 31.2 hp Gear: 34 hp; HST: 32 hp Engine Emissions Constraints Tier 4 Tier 4B (final) Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry Replaceable primary and inner elements Fuel System Common rail direct injection Electronically controlled common rail direct injection Alternator Not Published ROPS: 70 A, 12 V; Cab: 85 A, 12 V ▶ HydraulicsPump Type Engine-driven gear-type pump Gear Implement Flow Not Published 8.2 gpm Steering Flow Not Published Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow Not Published Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow 12.6 gpm Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 12.1 gpm Not Published No. of Standard Remote Valves Cab: 1 pair 1 No. of Optional Remote Valves Up to 3 Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 10.56 gal ROPS: 10.5 gal; Cab: 12.4 gal Coolant Capacity 6.34 qt 7.5 qt Crankcase Capacity 4.86 qt 5.8 qt Transmission / Hydraulic System Capacity 12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal 8.5 gal Front Axle Fluid Capacity 7.9 qt 6.87 qt ▶ PTO & HitchPTO Type Independent, with soft-start feature Independent, electro-hydraulic engagement PTO Rear 540 rpm (6-spline) 540 rpm Mid-PTO Availability Optional, 2,000 rpm Standard (2000 rpm) Category, 3-Point Hitch Category I with extendable ball ends Category I Hitch Lift Capacity Not Published 1,808 lb Hitch Lift Capacity (at 24”) 2,535 lb 1,345 lb Lift Control Type Draft control optional Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic Gear: 12x12 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite Gear: 12F/12R; HST: 3-range Max Travel Speed (Forward) Not Published Gear: 14.2 mph; HST: 14.8 mph Max Travel Speed (Reverse) Not Published Gear: 13.63 mph; HST: 13.60 mph Clutch Single stage dry type Gear: dry single disc (9.4 in); HST: n/a Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Internal wet disc brakes, independent foot pedals Wet multi-disc Seat Suspension & Adjustability Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth seat with weight control, easy fore/aft movement and adjustable armrests Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 64.2 in 66.4 in Wheelbase 69.7 in 66 in Ground Clearance 15.4 in Not Published Min. Turn Radius without Brakes Not Published 9.2 ft (with brake applied) Height to Top of ROPS 99.2 in 92.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.3 in 90 in Overall Length 122.0 in 119 in ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb ROPS Gear: 2,804 lb; ROPS HST: 2,870 lb; Cab: 3,574 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, Snow R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8-16 7-14 R1 Agricultural - Rear 12.4x24 11.2-24 R3 Turf - Front 27x8.50-15 25x8.50-14 R3 Turf - Rear 41x14.00-20 41x14.00-20 R4 Industrial - Front 10-16.5 25x8.50-14 R4 Industrial - Rear 17.5L-24 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System DL125: Pin-on (skid steer quick attach optional) Tool-free loader mount; optional skid-steer quick-attach plates Loader Model DL125 250TLA Loader Lift Height DL125: 106 in (at pivot pin) 250TLA: 104 in (at pivot pin) Loader Lift Capacity (Full Height) DL125: 1,660 lb (at pivot pin, full height) 250TLA: 1,822 lb (at bucket pivot pin, max height) Loader Breakout Force DL125: 3,000 lb (at pivot pin) 250TLA: 3,257 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Five-year powertrain warranty Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total)
