▶ EngineEngine Manufacturer Shibaura Kubota Engine Model N4LDI-T V2403-CR-E4-GL5 Engine Type 4-cylinder turbocharged intercooled diesel, liquid-cooled Naturally aspirated, multi-valve, liquid-cooled diesel No. of Cylinders 4 4 Displacement 135.2 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48.8 hp 49 hp PTO Power 38.1 hp 39.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry paper, dual element Fuel System Common rail direct injection Electronic CRS (Common Rail System) Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Engine-driven gear-type pump Tandem pump - gear type Implement Flow Not Published 9.4 gpm Steering Flow Not Published 4.7 gpm Total Hydraulic Flow Not Published 14.1 gpm Overall Hydraulic Pump Flow 12.6 gpm 14.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 12.1 gpm Not Published No. of Standard Remote Valves Cab: 1 pair None standard (up to 3 optional) No. of Optional Remote Valves Up to 3 Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity 14 gal 13.5 gal Coolant Capacity 7.08 qt 8.7 qt Crankcase Capacity 6.87 qt 8.7 qt Transmission / Hydraulic System Capacity 12x12 Power Shuttle: 10.04 gal; HST: 9.25 gal 11.4 gal Front Axle Fluid Capacity 9 qt 8.9 qt ▶ PTO & HitchPTO Type Independent, with soft-start feature Live independent (hydraulic clutch) PTO Rear 540 rpm (6-spline) 540 rpm @ 2475 engine rpm Mid-PTO Availability Optional, 2,000 rpm Optional Category, 3-Point Hitch Category I with extendable ball ends SAE Category I Hitch Lift Capacity Not Published 3,858 lb Hitch Lift Capacity (at 24”) 3,086 lb 2,756 lb Lift Control Type Draft control optional Position control ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic Hydrostatic No. of Speeds 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite 3-range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) Not Published 16.8 mph Max Travel Speed (Reverse) Not Published 15.1 mph Clutch Single stage dry type Not Published Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Internal wet disc brakes, independent foot pedals Wet disc type, mechanically activated Seat Suspension & Adjustability Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Deluxe suspension seat with swivel; Air-Ride seat (optional) Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Width 65.4 in 66.5 in Wheelbase 77.9 in 74.6 in Ground Clearance 14.8 in 14.4 in Min. Turn Radius without Brakes Not Published 8.9 ft (with brake applied) Height to Top of ROPS 102.4 in 97.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.9 in Not Applicable Overall Length 132.3 in 129.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 3,946 lb; HST: 4,045 lb 3,847 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, Snow R1 Agricultural; R3 Turf (Option 1) or R3 LSW Turf (Option 2); R4 Industrial R1 Agricultural - Front 9.5x16 8.3-16 R1 Agricultural - Rear 13.6x28 14.9-24 R3 Turf - Front 27x10.50-15 29x12.50-15 R3 Turf - Rear 44x18.00-20 44x18-20 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System DL135: Skid steer quick attach 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model DL135 LA1105 Loader Lift Height DL135: 111 in (at pivot pin) Not Published Loader Lift Capacity (Full Height) DL135: 2,610 lb (at pivot pin, full height) Not Published Loader Breakout Force DL135: 4,000 lb (at pivot pin) LA555: 2,030 lb; LA805: 2,549 lb; LA1055: 3,171 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
