▶ EngineEngine Manufacturer Shibaura Kubota Engine Model N4LDI-T V2403-CR-E5 Engine Type 4-cylinder turbocharged intercooled diesel, liquid-cooled Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 4 4 Displacement 135.2 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48.8 hp 48.4 hp PTO Power 38.1 hp 39 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry Dry type, primary and secondary element Fuel System Common rail direct injection Direct injection Alternator Not Published 45 A, 12 V ▶ HydraulicsPump Type Engine-driven gear-type pump Not Published Implement Flow Not Published 7.8 gpm Steering Flow Not Published 4.7 gpm Total Hydraulic Flow Not Published 12.5 gpm (7.8 + 4.7, computed) Overall Hydraulic Pump Flow 12.6 gpm 12.5 gpm (7.8 + 4.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 12.1 gpm Not Published No. of Standard Remote Valves Cab: 1 pair Not Published No. of Optional Remote Valves Up to 3 Optional: double-acting valve, or double-acting valve with float position (float valve as second segment only) ▶ Fluid CapacityFuel Tank Capacity 14 gal 13.5 gal Coolant Capacity 7.08 qt 6.9 qt Crankcase Capacity 6.87 qt 8.7 qt Transmission / Hydraulic System Capacity 12x12 Power Shuttle: 10.04 gal; HST: 9.25 gal 10.6 gal Front Axle Fluid Capacity 9 qt 6.9 qt ▶ PTO & HitchPTO Type Independent, with soft-start feature Live independent PTO with hydraulic clutch PTO Rear 540 rpm (6-spline) 540 rpm Mid-PTO Availability Optional, 2,000 rpm Not Published Category, 3-Point Hitch Category I with extendable ball ends SAE Category I Hitch Lift Capacity Not Published 2,870 lb Hitch Lift Capacity (at 24”) 3,086 lb 2,320 lb Lift Control Type Draft control optional Position control ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic Hydrostatic transmission (3-range) No. of Speeds 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite 3-range Max Travel Speed (Forward) Not Published 15.8 mph Max Travel Speed (Reverse) Not Published 14.2 mph Clutch Single stage dry type Not Applicable Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Internal wet disc brakes, independent foot pedals Mechanical, wet disc type Seat Suspension & Adjustability Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives Cast-iron front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,430 lb ▶ Dimensions & ManeuverabilityOverall Width 65.4 in 62.2 in Wheelbase 77.9 in 72.6 in Ground Clearance 14.8 in 15.2 in Min. Turn Radius without Brakes Not Published 8.5 ft (with brake applied) Height to Top of ROPS 102.4 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.9 in Not Published Overall Length 132.3 in 120.3 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 3,946 lb; HST: 4,045 lb 3,549 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, Snow Agricultural; Turf; Industrial (R4) R1 Agricultural - Front 9.5x16 8.3-16 R1 Agricultural - Rear 13.6x28 14.9-24 R3 Turf - Front 27x10.50-15 27X10.5-15 R3 Turf - Rear 44x18.00-20 44X18-20 R4 Industrial - Front 10-16.5 10.0-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System DL135: Skid steer quick attach LA766 2-Lever Quick Coupler Loader Model DL135 LA766 Loader Lift Height DL135: 111 in (at pivot pin) 105.2 in (at pivot pin) Loader Lift Capacity (Full Height) DL135: 2,610 lb (at pivot pin, full height) 1,676 lb (at pivot pin, max. height) Loader Breakout Force DL135: 4,000 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
