▶ EngineEngine Manufacturer Shibaura Iseki Engine Model N4LDI-T E4FH Engine Type 4-cylinder turbocharged intercooled diesel, liquid-cooled 4-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 4 4 Displacement 135.2 in³ 148.6 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48.8 hp 48.8 hp PTO Power 38.1 hp Mech: 38.1 hp; HST: 36.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry Dry Fuel System Common rail direct injection Common rail direct injection Alternator Not Published Not Published ▶ HydraulicsPump Type Engine-driven gear-type pump Two gear-type pumps for steering and 3-point/remotes Implement Flow Not Published 12.6 gpm Steering Flow Not Published 7 gpm Total Hydraulic Flow Not Published 19.6 gpm (12.6 + 7, computed) Overall Hydraulic Pump Flow 12.6 gpm 19.6 gpm (12.6 + 7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 12.1 gpm Not Published No. of Standard Remote Valves Cab: 1 pair Not Published No. of Optional Remote Valves Up to 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 14 gal 14.0 gal Coolant Capacity 7.08 qt 7.61 qt Crankcase Capacity 6.87 qt 7.82 qt Transmission / Hydraulic System Capacity 12x12 Power Shuttle: 10.04 gal; HST: 9.25 gal Power Shuttle: 10.04 gal; Hydrostatic: 9.25 gal Front Axle Fluid Capacity 9 qt 9 qt ▶ PTO & HitchPTO Type Independent, with soft-start feature Independent with SoftStart electronic modulation PTO Rear 540 rpm (6-spline) 540 rpm Mid-PTO Availability Optional, 2,000 rpm Optional, 2000 rpm Category, 3-Point Hitch Category I with extendable ball ends Category I and II Hitch Lift Capacity Not Published 3,483 lb Hitch Lift Capacity (at 24”) 3,086 lb 3,086 lb Lift Control Type Draft control optional Position control with optional draft control ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic 12x12 power shuttle or 3-range hydrostatic No. of Speeds 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite Power Shuttle: 12 forward and 12 reverse; HST: infinite forward and reverse (3-range) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Single stage dry type Not Published Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Internal wet disc brakes, independent foot pedals Wet disc Seat Suspension & Adjustability Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Open station: vinyl-clad seat; standard cab: spring-suspension seat with armrests; upgraded cab: air-suspension seat with armrests Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives Solid cast front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 65.4 in 70.1 in Wheelbase 77.9 in Not Published Ground Clearance 14.8 in 14.0 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 102.4 in 102.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.9 in 92.9 in Overall Length 132.3 in 132.3 in ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 3,946 lb; HST: 4,045 lb ROPS: 4,035 lb; Cab: 4,420 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, Snow R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5x16 9.5-16 R1 Agricultural - Rear 13.6x28 13.6-28 standard; 16.9-24 optional R3 Turf - Front 27x10.50-15 27x10.50-15 R3 Turf - Rear 44x18.00-20 44x18.00-20 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 17.5L-24 14.9-24; 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System DL135: Skid steer quick attach FL2814: skid steer quick attach Loader Model DL135 FL2814 Loader Lift Height DL135: 111 in (at pivot pin) FL2814: 111 in (at pivot pin) Loader Lift Capacity (Full Height) DL135: 2,610 lb (at pivot pin, full height) FL2814: 2,570 lb (at pivot pin) Loader Breakout Force DL135: 4,000 lb (at pivot pin) FL2814: 3,910 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Five-year powertrain warranty
