▶ EngineEngine Manufacturer Shibaura Kubota Engine Model N4LDI-TA V2403-CR-TE4 Engine Type 4-cylinder turbocharged intercooled diesel, liquid-cooled 4-cylinder, turbocharged, common-rail, liquid-cooled diesel No. of Cylinders 4 4 Displacement 135.2 in³ 148.6 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 53.9 hp 54.7 hp PTO Power Mech: 41.3 hp; HST: 39.7 hp F (2WD gear), DT (4WD gear): 45.7 hp; HST (4WD): 44.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry, dual element Fuel System Common rail direct injection Common rail direct injection Alternator Not Published 45 A ▶ HydraulicsPump Type Engine-driven gear-type pump Not Published Implement Flow Not Published 9.5 gpm Steering Flow Not Published 4.9 gpm Total Hydraulic Flow Not Published 14.4 gpm (9.5 + 4.9, computed) Overall Hydraulic Pump Flow 12.6 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 12.1 gpm Not Published No. of Standard Remote Valves Cab: 1 pair Not Published No. of Optional Remote Valves Up to 3 Up to 3 (optional) ▶ Fluid CapacityFuel Tank Capacity 14 gal 13.5 gal Coolant Capacity 7.08 qt 6.9 qt Crankcase Capacity 6.87 qt 9.9 qt Transmission / Hydraulic System Capacity Power Shuttle: 10.04 gal; HST: 9.25 gal 11.6 gal Front Axle Fluid Capacity 9 qt Not Published ▶ PTO & HitchPTO Type Independent, with soft-start feature Live independent hydraulic PTO with PTO brake, wet clutch PTO Rear 540 rpm (6-spline) 540 rpm Mid-PTO Availability Optional, 2,000 rpm Not Published Category, 3-Point Hitch Category I with extendable ball ends Category I and II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,086 lb 2,310 lb Lift Control Type Draft control optional Position control standard, draft control optional ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic F (2WD gear), DT (4WD gear): gear-drive with synchronized shuttle, 8F/8R (4-speed main, partially synchronized 3rd and 4th); HST (4WD): hydrostatic transmission, 3-range No. of Speeds 12 x 12 Power Shuttle (3 ranges, 4 gears); HST: 3-range, infinite speeds in each range F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range Max Travel Speed (Forward) Not Published F (2WD gear), DT (4WD gear): 16.0 mph; HST (4WD): 16.1 mph Max Travel Speed (Reverse) Not Published F (2WD gear), DT (4WD gear): 14.7 mph; HST (4WD): 14.5 mph Clutch Single stage dry type F (2WD gear), DT (4WD gear): dry single plate; HST (4WD): no clutch Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Power steering Hydrostatic power steering Brakes Internal wet disc brakes, independent foot pedals Mechanical wet disc Seat Suspension & Adjustability Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering High-back suspension seat Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives 4WD: Bevel gear type Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,650 lb ▶ Dimensions & ManeuverabilityOverall Width 65.4 in 69.7 in Wheelbase 77.9 in 74.6 in Ground Clearance 14.8 in 15.2 in Min. Turn Radius without Brakes Not Published F (2WD gear): 8.5 ft; DT (4WD gear), HST (4WD): 8.9 ft (with brake applied) Height to Top of ROPS 102.4 in 95.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.9 in Not Published Overall Length 132.3 in F (2WD gear): 127.8 in; DT (4WD gear), HST (4WD): 125.2 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 3,968 lb (ROPS base weight) F (2WD gear): 3,474 lb; DT (4WD gear): 3,716 lb; HST (4WD): 3,734 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options AG, Turf, Industrial, Snow Standard ag: 7.5L-15 (2WD) or 9.5-16 (4WD) front, 14.9-26 rear R1 Agricultural - Front 9.5x16 F (2WD gear): 7.5L-15; DT (4WD gear), HST (4WD): 9.5-16 R1 Agricultural - Rear 13.6x28 14.9-26 R3 Turf - Front 27x10.50-15 Not Published R3 Turf - Rear 44x18.00-20 Not Published R4 Industrial - Front 10-16.5 Not Published R4 Industrial - Rear 17.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System DL135: Skid steer quick attach LA1065: 2-lever quick coupler standard Loader Model DL135 LA1065 Loader Lift Height DL135: 111 in (at pivot pin) LA1065: 111.2 in (at pivot pin) Loader Lift Capacity (Full Height) DL135: 2,610 lb (at pivot pin, full height) LA1065: 2,275 lb (at pivot pin) Loader Breakout Force DL135: 4,000 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Five-year powertrain warranty Not Published
