▶ EngineEngine Manufacturer Iseki Iseki Engine Model E3112 E3112 Engine Type 3-cylinder, liquid-cooled diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 68.5 in³ 68.5 in³ Rated Engine Speed 3000 rpm 3000 rpm Engine Power (Gross) 24.5 hp 24.5 hp PTO Power 18.5 hp 19.6 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Not Published Indirect injection Alternator Not Published 40 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow Not Published 4.9 gpm Steering Flow Not Published 2.0 gpm Total Hydraulic Flow 6.8 gpm 6.8 gpm Overall Hydraulic Pump Flow 6.8 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity Not Published 1.23 gal Crankcase Capacity Not Published 0.68 gal Transmission / Hydraulic System Capacity Not Published 2.9 gal Front Axle Fluid Capacity Not Published 1.05 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm, 1.375 in six spline 540 rpm (1.375 in, six spline) Mid-PTO Availability Independent, 2000 rpm Independent, 2000 rpm (1 in, fifteen spline) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,191 lb 1,191 lb Hitch Lift Capacity (at 24”) 661 lb 661 lb Lift Control Type Not Published Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic 2-range hydrostatic with side-by-side foot pedals and cruise control No. of Speeds Infinite forward and reverse (2-range) Infinite forward and reverse (2-range hydrostatic) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Locking rear differential (4WD) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Power steering Brakes Not Published Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 4WD front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 46.7 in (minimum width, with R1 tires) Wheelbase Not Published 57.1 in Ground Clearance Not Published 6.7 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 85.5 in 72.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length Not Published 97.6 in ▶ WeightTractor Weight (Base) Not Published 1,532 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, R4 Industrial AG, Turf or R4 Industrial: front 18x8.50-10, rear 26x12.00-12 R1 Agricultural - Front 18x8.50-10 18x8.50-10 R1 Agricultural - Rear 26x12.00-12 26x12.00-12 R3 Turf - Front Not Published 18x8.50-10 R3 Turf - Rear Not Published 26x12.00-12 R4 Industrial - Front Not Published 18x8.50-10 R4 Industrial - Rear Not Published 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System Skid Steer Quick Attach Skid steer quick attach Loader Model FL1805 FL1805 Loader Lift Height FL1805: 74 in (at pivot pin) 74 in Loader Lift Capacity (Full Height) FL1805: 922 lb (at pivot pin) 922 lb Loader Breakout Force FL1805: 1,392 lb (at pivot pin) 1,392 lb ▶ WarrantyWarranty Length & Coverage Not Published Five-year powertrain warranty
