▶ EnginePTO Power Not Published 54.1 hp Alternator Not Published 70 A, 12 V Air Cleaner Dry Type / Oil Bath Dry Engine Type 4-cylinder diesel In-line vertical, water cooled 4-cycle diesel, CRDI Fuel System Not Published Delphi, CRDI Displacement 219.7 in³ 152.9 in³ No. of Cylinders 4 4 Rated Engine Speed 2200 rpm 2500 rpm Cooling System Type Not Published Water-cooled Engine Manufacturer Simpson LS Mtron Engine Power (Gross) 63 hp 63 hp Engine Emissions Constraints Not Published Tier 4 ▶ WeightWeight with ROPS and Loader Not Published 6,503 lb Weight with Cab and Loader Not Published Not Applicable ▶ WarrantyWarranty Length & Coverage Not Published 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty ▶ HydraulicsPump Type Scotch yoke pump (rear axle mounted) Gear type, engine drive Steering Flow 5.3 gpm 6.8 gpm Implement Flow 4.8 gpm 14.9 gpm Total Hydraulic Flow 10.0 gpm 21.7 gpm Hydraulic System Type Open centre Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 10.0 gpm 21.7 gpm No. of Optional Remote Valves Not Published Not Published No. of Standard Remote Valves Not Published 2 Pairs (Front), 2 Pairs (Rear) ▶ PTO & HitchPTO Rear 540 rpm 540 / 540E PTO Type Live PTO Independent Lift Control Type Ferguson System Position & Draft Hitch Lift Capacity 4,519 lb 4,079 lbs Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Not Published Category II Hitch Lift Capacity (at 24”) Not Published 3,483 lbs ▶ Tire OptionsR3 Turf - Rear Not Published Not Published R3 Turf - Front Not Published Not Published Tire Size & Options R1 Agricultural Multiple options available (Standard Ag, Industrial, Large Ag, R14) R4 Industrial - Rear Not Published 19.5LX24 R4 Industrial - Front Not Published 10.5/80X18 R1 Agricultural - Rear 16.9X28 16.9-30 R1 Agricultural - Front 2WD: 7.50X16; 4WD: 9.5X24 11.2-24 ▶ Fluid CapacityCoolant Capacity Not Published 3.0 gal Crankcase Capacity Not Published 1.8 gal Fuel Tank Capacity 15.9 gal 24.3 gal Front Axle Fluid Capacity Not Published 2.3 gal Transmission / Hydraulic System Capacity Not Published 16.5 gal ▶ Loader & AttachmentsLoader Lift Height Not Published 132.9 in Loader Breakout Force Not Published Not Published Quick Attach Loader System Not Published LL5001: Standard Quick-Attach, Skid-Steer Compatible (SSQA) Loader Lift Capacity (Full Height) Not Published 3,488 lb ▶ Transmission & DrivetrainClutch Dual Dry Plate Dry single clutch No. of Speeds 8F / 2R F16 X R16 Transmission Type Sliding mesh gearbox Synchro Shuttle Max Travel Speed (Forward) 18.6 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Mechanical differential lock (foot pedal) Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsBrakes Oil immersed, mechanical actuation Wet, Multi-disc Steering Hydrostatic Hydrostatic Power Steering Frame Type Not Published Not Published Front Axle Type Not Published Not Published Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Seat With Suspension & Armrest ▶ Dimensions & ManeuverabilityWheelbase 80.7 in 83.1 in Overall Width Not Published 72.6 in Ground Clearance Not Published Not Published Height to Top of ROPS 99.2 in 113.9 in Height to Top of Cab Model Not Published Not Applicable Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published 12.8 ft (3.9 m) Overall Length with 3-Point Hitch 153.1 in 154 in
