▶ EngineEngine Manufacturer Iseki KIOTI Engine Model Not Published 4F243T Engine Type 4-cylinder, turbocharged diesel In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4F243T) No. of Cylinders 4 4 Displacement Not Published 148.6 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 65.7 hp 66 hp PTO Power 50 hp 57.6 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Water-cooled Air Cleaner Not Published Dry element Fuel System Not Published Common Rail Direct Injection (CRDI) Alternator Not Published Not Published ▶ HydraulicsPump Type Two gear-type pumps Gear Implement Flow 12.6 gpm 11.0 gpm Steering Flow 7.1 gpm 6.9 gpm Total Hydraulic Flow 19.7 gpm (12.6 + 7.1, computed) 17.9 gpm Overall Hydraulic Pump Flow 19.7 gpm (12.6 + 7.1, computed) 17.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 14.0 gal 22.5 gal Coolant Capacity Not Published 2.40 gal Crankcase Capacity Not Published 2.2 gal Transmission / Hydraulic System Capacity Not Published 15.9 gal Front Axle Fluid Capacity Not Published 2.2 gal ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation Independent PTO Rear 540 rpm 540 / 540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I & II Category II Hitch Lift Capacity 3,483 lb 4,575 lb Hitch Lift Capacity (at 24”) 3,483 lb 3,594 lb Lift Control Type Not Published Position, Draft, Mixed Control ▶ Transmission & DrivetrainTransmission Type 3-range Servo-HST with 2 stages (Hi and Lo), electronically controlled Manual: Power Shuttle No. of Speeds Not Published 12 forward / 12 reverse Max Travel Speed (Forward) Not Published 21.79 mph Max Travel Speed (Reverse) Not Published 21.42 mph Clutch Not Published Wet Disc Differential Lock & Limited Slip Options Not Published Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Hydrostatic Power Steering Brakes Not Published Wet Multi Disc Seat Suspension & Adjustability Not Published Adjustable Seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 132.3 in 145.0 in Overall Width 70.1 in 70.9 in Wheelbase Not Published 82.7 in Ground Clearance 14.0 in 16.5 in Min. Turn Radius without Brakes Not Published 10.2 ft (with brake applied) Height to Top of ROPS Not Published 105.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.9 in Not Published ▶ WeightTractor Weight (Base) 4,608 lb 5,148 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 9.5-20 R1 Agricultural - Rear Not Published 14.9-28 R3 Turf - Front Not Published 31x13.5-15/8 R3 Turf - Rear Not Published 44x18-20/4 R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 18.4-24/8 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer Built-in parking stand; designed to be quickly and easily attached and detached. Loader Model FL2814 KL7320 Loader Lift Height FL2814: 111 in KL7320: 133.9 in (to pivot pin) Loader Lift Capacity (Full Height) FL2814: 2,570 lb KL7320: 3,384 lb (to full height at pivot pins) Loader Breakout Force FL2814: 3,910 lb KL7320: 5,359 lb (at pivot pins) ▶ WarrantyWarranty Length & Coverage Not Published Tractors (Non-Commercial Application): 24 months parts & labor; Extended (Non-Commercial, driveline/powertrain): 48 months parts & labor; Limited time: eligible units receive total 6 years (72 months) extended powertrain warranty coverage.
