▶ EngineEngine Manufacturer Iseki Shibaura Engine Model Not Published Shibaura N4LDI-TA Engine Type 4-cylinder, turbocharged diesel 4-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders 4 4 Displacement Not Published 135.2 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 65.7 hp 59.9 hp PTO Power 50 hp 46.1 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Dry Fuel System Not Published Common rail direct injection Alternator Not Published Not Published ▶ HydraulicsPump Type Two gear-type pumps Engine-driven gear-type pump Implement Flow 12.6 gpm Not Published Steering Flow 7.1 gpm Not Published Total Hydraulic Flow 19.7 gpm (12.6 + 7.1, computed) Not Published Overall Hydraulic Pump Flow 19.7 gpm (12.6 + 7.1, computed) 12x12 Power Shuttle: 12.7 gpm; HST: 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 12.1 gpm No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity 14.0 gal 14.0 gal Coolant Capacity Not Published 7.08 qt Crankcase Capacity Not Published 6.87 qt Transmission / Hydraulic System Capacity Not Published 12x12 Power Shuttle: 11.35 gal; HST: 9.25 gal Front Axle Fluid Capacity Not Published 9.0 qt ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation Independent, with soft-start feature PTO Rear 540 rpm 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Not Published Optional, 2,000 rpm (not offered with the 12x12 power shuttle) Category, 3-Point Hitch Category I & II Category I with extendable ball ends Hitch Lift Capacity 3,483 lb Not Published Hitch Lift Capacity (at 24”) 3,483 lb 12x12 Power Shuttle: 3,307 lb; HST: 3,086 lb Lift Control Type Not Published Position and draft control ▶ Transmission & DrivetrainTransmission Type 3-range Servo-HST with 2 stages (Hi and Lo), electronically controlled 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds Not Published 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Multiple stage wet type Differential Lock & Limited Slip Options Not Published Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Power steering Brakes Not Published Internal wet disc brakes, individual control via independent foot pedals Seat Suspension & Adjustability Not Published Deluxe suspended seat with armrests and seatbelts (vinyl seat on ROPS, cloth seat on cab), tilt steering Front Axle Type Not Published Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 132.3 in 12x12 Power Shuttle: 170.1 in; HST: 132.3 in Overall Width 70.1 in 12x12 Power Shuttle: 71.1 in; HST: 65.4 in Wheelbase Not Published 12x12 Power Shuttle: 80.3 in; HST: 77.9 in Ground Clearance 14.0 in 14.8 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 12x12 Power Shuttle: 103.2 in; HST: 102.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.9 in 12x12 Power Shuttle: 93.3 in; HST: 92.9 in ▶ WeightTractor Weight (Base) 4,608 lb 12x12 Power Shuttle: 4,233 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 9.5x16 R1 Agricultural - Rear Not Published 16.9x26 R3 Turf - Front Not Published 27x10.50-15 R3 Turf - Rear Not Published 44x18.00-20 R4 Industrial - Front Not Published 12-16.5 R4 Industrial - Rear Not Published 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer DL135: Skid steer quick attach Loader Model FL2814 DL135 Loader Lift Height FL2814: 111 in DL135: 111 in Loader Lift Capacity (Full Height) FL2814: 2,570 lb DL135: 2,610 lb Loader Breakout Force FL2814: 3,910 lb DL135: 4,000 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
