▶ EngineEngine Manufacturer AGCO Power Kubota Engine Model Not Published V3800CR-TIEF4 Engine Type 4-cylinder, turbocharged intercooled diesel 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR No. of Cylinders 4 4 Displacement 268.5 in³ 230 in³ Rated Engine Speed 2200 rpm 2400 rpm Engine Power (Gross) 105 hp 105.6 hp PTO Power 80 hp 89 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System High-pressure common-rail direct fuel injection Common rail direct injection Alternator Platform: 80 A; Cab: 120 A 60 A ▶ HydraulicsPump Type Engine-driven gear pump Gear pump Implement Flow 26 gpm 15.7 gpm Steering Flow 8.5 gpm 5.4 gpm Total Hydraulic Flow Not Published 21.3 gpm Overall Hydraulic Pump Flow Not Published 21.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 26 gpm 15.7 gpm No. of Standard Remote Valves 2 2 (max 3) No. of Optional Remote Valves One (3rd valve optional) 1 (3 maximum) ▶ Fluid CapacityFuel Tank Capacity 52.8 gal 27.7 gal Coolant Capacity Not Published 11 qt Crankcase Capacity Not Published 11.3 qt Transmission / Hydraulic System Capacity Not Published 63.4 qt Front Axle Fluid Capacity Not Published 6.3 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 / 540E / 1000 rpm 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 9,480 lb 7,055 lb (8,600 lb optional) Hitch Lift Capacity (at 24”) 7,500 lb 5,181 lb Lift Control Type Not Published Position, draft (top link sensing) and mixed control ▶ Transmission & DrivetrainTransmission Type 12 x 12: 2-range power shuttle with electrohydraulic shuttle lever; Dyna-4: powershift Fully synchronized main gear shift with electro-hydraulic shuttle No. of Speeds 12 x 12: 12F/12R; Dyna-4: 16F/16R 8 forward, 8 reverse Max Travel Speed (Forward) Not Published 18.6 mph Max Travel Speed (Reverse) Not Published 18.4 mph Clutch Multidisk wet clutch with electrohydraulic power shuttle lever Multiple wet disc Differential Lock & Limited Slip Options Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Hydraulic wet disc Seat Suspension & Adjustability ROPS: mechanical spring suspension with armrests; Cab: air-ride swivel seat Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Front Axle Type Heavy-duty 4WD front axle Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5,730 lb Drawbar Capacity Not Published 3,300 lb ▶ Dimensions & ManeuverabilityOverall Width Dyna-4 cab: 74.9 in; 12 x 12 cab: 79.8 in 79.1 in Wheelbase 95.7 in 88.6 in Ground Clearance Not Published 17.7 in (drawbar bracket) Min. Turn Radius without Brakes Not Published 13.8 ft Height to Top of ROPS Not Published 99.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Applicable Overall Length Not Published 155.9 in ▶ WeightTractor Weight (Base) ROPS: 9,195 lb; Cab: 10,011 lb 6,283 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 R1 Agricultural - Front Not Published 12.4-24 R1 Agricultural - Rear Not Published 18.4-30 R3 Turf - Front Not Published 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) R3 Turf - Rear Not Published 18.4-26 R3 or 19.5L-24 R3 R4 Industrial - Front Not Published 9.5L-15 F2 (rib front paired with the R4 rear) R4 Industrial - Rear Not Published 19.5L-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional Loader Model Not Published LA1854 Loader Lift Height Not Published 145.7 in (height position); 131.9 in (power position) Loader Lift Capacity (Full Height) Not Published 3,990 lb (height position); 4,144 lb (power position) Loader Breakout Force Not Published LA1854: 5,501 lbf (height position); 6,470 lbf (power position) ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
