▶ EngineEngine Manufacturer AGCO Power AGCO Power Engine Model Not Published Not Published Engine Type 4-cylinder, turbocharged intercooled diesel 3-cylinder, intercooled turbocharged diesel No. of Cylinders 4 3 Displacement 268.5 in³ 201 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 105 hp 100 hp PTO Power 80 hp 87 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid cooled Air Cleaner Not Published Dual element (primary and secondary) Fuel System High-pressure common-rail direct fuel injection High-pressure common rail direct fuel injection Alternator Platform: 80 A; Cab: 120 A 80 A ▶ HydraulicsPump Type Engine-driven gear pump Two-stage pump Implement Flow 15.3 gpm Not Published Steering Flow 8.5 gpm Not Published Total Hydraulic Flow 23.8 gpm (15.3 + 8.5, computed) Not Published Overall Hydraulic Pump Flow 23.8 gpm (15.3 + 8.5, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 26 gpm 17.2 gpm No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 3 1 ▶ Fluid CapacityFuel Tank Capacity 52.8 gal 33 gal Coolant Capacity Not Published 4.2 gal Crankcase Capacity Not Published 3.3 gal Transmission / Hydraulic System Capacity Not Published Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal Front Axle Fluid Capacity Not Published Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Independent, electrohydraulic engagement PTO Rear 540 / 540E / 1000 rpm 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 9,480 lb Not Published Hitch Lift Capacity (at 24”) 7,500 lb 4,850 lb Lift Control Type Not Published Not Published ▶ Transmission & DrivetrainTransmission Type 12 x 12: 2-range power shuttle with electrohydraulic shuttle lever; Dyna-4: semi-powershift 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift No. of Speeds 12 x 12: 12F/12R; Dyna-4: 16F/16R 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 Max Travel Speed (Forward) Not Published 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Multidisk wet clutch with electrohydraulic power shuttle lever Multidisc wet clutch with easy shift knob and electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch; 4WD front axle Hydra-Lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Cab: tilt and telescopic steering column; Platform: tilt steering column Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability ROPS: mechanical spring suspension with armrests; Cab: air-ride swivel seat Cab: mechanical swiveling seat with armrests, air-ride swivel seat optional; Platform: mechanical spring suspension seat with armrests Front Axle Type Heavy-duty 4WD front axle Heavy-duty 2WD or 4WD front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 165.6 in Not Published Overall Width Dyna-4 cab: 74.9 in; 12 x 12 cab: 79.8 in 60.3 in (minimum, with std. 420/85R30 rear tires) Wheelbase 95.7 in 88.5 in Ground Clearance 20.3 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 105.7 in Not Published ▶ WeightTractor Weight (Base) ROPS: 9,195 lb; Cab: 10,011 lb 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 2WD: 9.5L-15 front, 420/85R34 rear; 4WD: 340/85R24 front, 420/85R34 rear R1 Agricultural - Front Not Published 2WD: 9.5L-15; 4WD: 340/85R24 R1 Agricultural - Rear Not Published 420/85R34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published 931X and 936X: universal skid steer type quick release Loader Model Not Published FL.3522, FL.3615, 931X, 936X Loader Lift Height Not Published FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) Loader Lift Capacity (Full Height) Not Published FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
