▶ EngineEngine Manufacturer AGCO Power KIOTI (Daedong) Engine Model Not Published 4J243TA-TP5B Engine Type 4-cylinder, turbocharged intercooled diesel In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4J243TA-TP5B) No. of Cylinders 4 4 Displacement 268.5 in³ 233.9 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 115 hp 115.3 hp PTO Power 90 hp 83.9 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid cooled Water-cooled Air Cleaner Not Published Dry element with evacuator valve Fuel System High-pressure common-rail direct fuel injection Common Rail Direct Injection (CRDI) Alternator Platform: 80 A; Cab: 120 A Not Published ▶ HydraulicsPump Type Engine-driven gear pump Gear Implement Flow 15.3 gpm 19.8 gpm Steering Flow 8.5 gpm 12.2 gpm Total Hydraulic Flow 23.8 gpm (15.3 + 8.5, computed) 32 gpm Overall Hydraulic Pump Flow 23.8 gpm (15.3 + 8.5, computed) 32 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 26 gpm Not Published No. of Standard Remote Valves 2 3 No. of Optional Remote Valves 3 1 ▶ Fluid CapacityFuel Tank Capacity 52.8 gal 47.6 gal Coolant Capacity Not Published 4.7 gal Crankcase Capacity Not Published 3.9 gal Transmission / Hydraulic System Capacity Not Published 20.34 gal Front Axle Fluid Capacity Not Published 2.6 gal ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Independent PTO Rear 540 / 540E / 1000 rpm 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 9,480 lb 8,079 lb Hitch Lift Capacity (at 24”) 7,500 lb 8,002 lb Lift Control Type Not Published Electronic control ▶ Transmission & DrivetrainTransmission Type 12 x 12: 2-range power shuttle with electrohydraulic shuttle lever; Dyna-4: semi-powershift Power Shuttle w/ Hi-Lo Shift No. of Speeds 12 x 12: 12F/12R; Dyna-4: 16F/16R 24 forward / 24 reverse Max Travel Speed (Forward) Not Published 23.83 mph Max Travel Speed (Reverse) Not Published 23.67 mph Clutch Multidisk wet clutch with electrohydraulic power shuttle lever Wet Multi Disc Differential Lock & Limited Slip Options Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch Mechanical rear differential lock (standard); front limited-slip differential ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Power Steering Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Wet Multi Disc Seat Suspension & Adjustability ROPS: mechanical spring suspension with armrests; Cab: air-ride swivel seat Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft Front Axle Type Heavy-duty 4WD front axle 4WD with outboard planetary final drives and limited-slip differential Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 165.6 in 170.8 in Overall Width Dyna-4 cab: 74.9 in; 12 x 12 cab: 79.8 in 88.6 in Wheelbase 95.7 in 94.9 in Ground Clearance 20.3 in 18.9 in Min. Turn Radius without Brakes Not Published 12.7 ft (with brake applied) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 105.7 in 111.9 in ▶ WeightTractor Weight (Base) ROPS: 9,195 lb; Cab: 10,011 lb 10,230 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) R1 Agricultural - Front Not Published 13.6-24 R1 Agricultural - Rear Not Published 18.4-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator Loader Model Not Published KL1155 Loader Lift Height Not Published KL1155: 150.6 in (to pivot pin) Loader Lift Capacity (Full Height) Not Published KL1155: 4,216 lb (at pivot pins) Loader Breakout Force Not Published KL1155: 8,554 lb (at pivot pins) ▶ WarrantyWarranty Length & Coverage Not Published Tractors (Non-Commercial): 24 months parts & labor, unlimited hours, 0% deductible; powertrain (engine and driveline): 48 months unlimited hours on HX Series
