▶ EngineEngine Manufacturer AGCO Power Kubota Engine Model Not Published V3800-TI-CRS Engine Type 4-cylinder, turbocharged intercooled diesel 4-cylinder, turbocharged and intercooled, common-rail, liquid-cooled diesel No. of Cylinders 4 4 Displacement 268.5 in³ 230 in³ Rated Engine Speed 2200 rpm 2600 rpm Engine Power (Gross) 115 hp 114.1 hp PTO Power 90 hp 92 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled, pressurized radiator, recovery tank Air Cleaner Not Published 8 in dry, dual element Fuel System High-pressure common-rail direct fuel injection Common rail direct injection Alternator Platform: 80 A; Cab: 120 A 130 A, 12 V ▶ HydraulicsPump Type Engine-driven gear pump Gear pumps Implement Flow 26 gpm 18.7 gpm Steering Flow 8.5 gpm 16.0 gpm Total Hydraulic Flow Not Published 34.7 gpm (18.7 + 16.0, computed) Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Pressure compensated, fixed displacement Rear Remote Hydraulic Flow 26 gpm 18.7 gpm No. of Standard Remote Valves 2 2 (with built-in flow control) No. of Optional Remote Valves One (3rd valve optional) 3rd and 4th optional (4 max) ▶ Fluid CapacityFuel Tank Capacity 52.8 gal 50.2 gal Coolant Capacity Not Published 11.3 qt Crankcase Capacity Not Published 11.3 qt Transmission / Hydraulic System Capacity Not Published 17.2 gal Front Axle Fluid Capacity Not Published 7.2 qt (differential) plus 3.8 qt per bevel gear case ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 / 540E / 1000 rpm 540/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 9,480 lb 8,598 lb Hitch Lift Capacity (at 24”) 7,500 lb 6,834 lb (optional 9,447 lb) Lift Control Type Not Published Electronic draft control, lower-link sensing; left fender-mounted hitch switch standard ▶ Transmission & DrivetrainTransmission Type 12 x 12: 2-range power shuttle with electrohydraulic shuttle lever; Dyna-4: powershift 24F/24R powershift (8-speed main, 3-speed mechanical range, clutch button, microprocessor-controlled electro-hydraulic shuttle); 32F/32R optional with creep No. of Speeds 12 x 12: 12F/12R; Dyna-4: 16F/16R 24F/24R (32F/32R with optional creep) Max Travel Speed (Forward) Not Published 23.4 mph Max Travel Speed (Reverse) Not Published 22.33 mph (with 18.4R38 tires, at rated rpm) Clutch Multidisk wet clutch with electrohydraulic power shuttle lever Multiple wet disc, electro-hydraulically operated, 5.2 in Differential Lock & Limited Slip Options Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch Electro-hydraulic front differential lock; rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Certified ROPS cab standard Steering Power steering Hydrostatic power steering Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Hydraulically operated wet disc brakes with automatic front axle engagement (4WD) Seat Suspension & Adjustability ROPS: mechanical spring suspension with armrests; Cab: air-ride swivel seat Air-suspension seat, swivel, reclining, fully adjustable (height, weight, fore-aft), armrests, retractable seat belt Front Axle Type Heavy-duty 4WD front axle 4WD, bevel-gear type, on-the-go electro-hydraulic engagement, electro-hydraulic front differential lock Front Axle Rating Not Published 6,610 lb at 62.2 in tread (9,700 lb with loader) Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Dyna-4 cab: 74.9 in; 12 x 12 cab: 79.8 in 82.7 in Wheelbase 95.7 in 95.9 in Ground Clearance Not Published 19.5 in (crop clearance) Min. Turn Radius without Brakes Not Published 13.1 ft (with Bi-Speed turn, 4WD on) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 111.8 in Overall Length Not Published 165.4 in ▶ WeightTractor Weight (Base) ROPS: 9,195 lb; Cab: 10,011 lb 9,788 lb (with standard tire) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Standard: 13.6 R24 front, 18.4 R34 rear (R1 options 12.4-24, 13.6-24 front; 16.9-34, 18.4R30, 18.4-34 rear) R1 Agricultural - Front Not Published 13.6 R24 R1 Agricultural - Rear Not Published 18.4 R34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA1955: 2-lever quick coupler or Euro quick coupler; single-lever hydraulic quick coupler; quick attach/detach loader with boom stands, two mounting pins Loader Model Not Published LA1955 Loader Lift Height Not Published LA1955 (height position): 145.7 in; LA1955 (power position): 132.7 in Loader Lift Capacity (Full Height) Not Published LA1955 (height position): 4,178 lb at pivot pin; LA1955 (power position): 4,299 lb at pivot pin Loader Breakout Force Not Published LA1955 (height position): 5,589 lbf at pivot pin; LA1955 (power position): 6,576 lbf at pivot pin ▶ WarrantyWarranty Length & Coverage Not Published Not Published
