▶ EngineEngine Manufacturer AGCO Power Doosan Engine Model Not Published Not Published Engine Type 4-cylinder, turbocharged intercooled diesel Turbocharged, four stroke intercooled, direct injection diesel No. of Cylinders 4 4 Displacement 268.5 in³ 208 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 115 hp 105 hp PTO Power 90 hp 95.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System High-pressure common-rail direct fuel injection Direct injection Alternator Platform: 80 A; Cab: 120 A 85 A ▶ HydraulicsPump Type Engine-driven gear pump Not Published Implement Flow 15.3 gpm 15.6 gpm Steering Flow 8.5 gpm 7.1 gpm Total Hydraulic Flow 23.8 gpm (15.3 + 8.5, computed) Not Published Overall Hydraulic Pump Flow 23.8 gpm (15.3 + 8.5, computed) Not Published Hydraulic System Type Open center Open center, full-live electro-hydraulic with position and draft controls Rear Remote Hydraulic Flow 26 gpm Not Published No. of Standard Remote Valves 2 3 (mFORCE 105P); 2 (mFORCE 105S) No. of Optional Remote Valves 3 1 ▶ Fluid CapacityFuel Tank Capacity 52.8 gal 33.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Electro-hydraulic PTO Rear 540 / 540E / 1000 rpm 540 @ 2220 rpm, 750 @ 2208 rpm, 1000 @ 2227 rpm (mFORCE 105P); 540 @ 2220 rpm, 1000 @ 2227 rpm (mFORCE 105S) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category 2 ball joints with telescopic lower links and adjustable outside stabilizers Hitch Lift Capacity 9,480 lb Not Published Hitch Lift Capacity (at 24”) 7,500 lb 6,860 lb Lift Control Type Not Published Position and draft control ▶ Transmission & DrivetrainTransmission Type 12 x 12: 2-range power shuttle with electrohydraulic shuttle lever; Dyna-4: semi-powershift Power shuttle, power shift with synchromesh (mFORCE 105P); power shuttle with synchromesh (mFORCE 105S) No. of Speeds 12 x 12: 12F/12R; Dyna-4: 16F/16R 24F / 24R + 8 creepers (mFORCE 105P); 12F / 12R (mFORCE 105S) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Multidisk wet clutch with electrohydraulic power shuttle lever Wet multi-plate Differential Lock & Limited Slip Options Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power with tiltable column Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Wet disc Seat Suspension & Adjustability ROPS: mechanical spring suspension with armrests; Cab: air-ride swivel seat Pneumatic suspension seat Front Axle Type Heavy-duty 4WD front axle Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 165.6 in 162 in Overall Width Dyna-4 cab: 74.9 in; 12 x 12 cab: 79.8 in 84.3 in Wheelbase 95.7 in Not Published Ground Clearance 20.3 in Not Published Min. Turn Radius without Brakes Not Published 11.98 ft Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 105.7 in 107 in ▶ WeightTractor Weight (Base) ROPS: 9,195 lb; Cab: 10,011 lb 8,666 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published 13.6R 24 R1 Agricultural - Rear Not Published 18.4R 34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model Not Published 105L Loader Lift Height Not Published 105L: 141.7 in Loader Lift Capacity (Full Height) Not Published 105L: 4,129 lb Loader Breakout Force Not Published 105L: 6,025 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year limited powertrain warranty
