▶ EngineEngine Manufacturer AGCO Power AGCO Power Engine Model Not Published Not Published Engine Type 4-cylinder, turbocharged intercooled diesel 4-cylinder, intercooled turbocharged, liquid-cooled diesel No. of Cylinders 4 4 Displacement 268.5 in³ 268.5 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 115 hp 130 hp PTO Power 90 hp 109 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System High-pressure common-rail direct fuel injection High-pressure common-rail direct injection (HPCR) Alternator Platform: 80 A; Cab: 120 A 120 A, 12 V ▶ HydraulicsPump Type Engine-driven gear pump Two high-pressure gear pumps Implement Flow 15.3 gpm 15.1 gpm Steering Flow 8.5 gpm Not Published Total Hydraulic Flow 23.8 gpm (15.3 + 8.5, computed) 25.9 gpm Overall Hydraulic Pump Flow 23.8 gpm (15.3 + 8.5, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 26 gpm 26 gpm No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 3 1 ▶ Fluid CapacityFuel Tank Capacity 52.8 gal 38.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Independent, electro-hydraulic engagement via switch PTO Rear 540 / 540E / 1000 rpm 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 9,480 lb Not Published Hitch Lift Capacity (at 24”) 7,500 lb 9,390 lb Lift Control Type Not Published Electronic linkage control (ELC) ▶ Transmission & DrivetrainTransmission Type 12 x 12: 2-range power shuttle with electrohydraulic shuttle lever; Dyna-4: semi-powershift 12F x 12R, 2-range power shuttle with electrohydraulic shuttle lever No. of Speeds 12 x 12: 12F/12R; Dyna-4: 16F/16R 12 forward, 12 reverse Max Travel Speed (Forward) Not Published 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Multidisk wet clutch with electrohydraulic power shuttle lever Single-plate wet clutch with easy shift knob and electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch Rear differential lock engaged via electrohydraulic rocker switch; Hydra-Lock hydraulic front axle differential lock on 4WD ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering; cab: tilt and telescopic column, platform: tilt column Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability ROPS: mechanical spring suspension with armrests; Cab: air-ride swivel seat Cab: air-ride swivel seat; platform: mechanical spring suspension seat with armrests Front Axle Type Heavy-duty 4WD front axle Heavy-duty 4WD front axle: cast steel, fixed, center drive line, planetary final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 165.6 in Not Published Overall Width Dyna-4 cab: 74.9 in; 12 x 12 cab: 79.8 in 64.8 in Wheelbase 95.7 in 98.4 in Ground Clearance 20.3 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 105.7 in Not Published ▶ WeightTractor Weight (Base) ROPS: 9,195 lb; Cab: 10,011 lb 4WD ROPS: 9,371 lb; 4WD Cab: 10,187 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Rear: 460/85R34 standard radial R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model Not Published 941X; 946X; FL.3723; FL.3819 Loader Lift Height Not Published 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in Loader Lift Capacity (Full Height) Not Published 941X: 3,650 lb; FL.3723: 4,519.5 lb Loader Breakout Force Not Published FL.3723: 5,818.6 lb; FL.3819: 4,892.9 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
