▶ EngineEngine Manufacturer Mitsubishi YANMAR Engine Model S3L2 3TNV88F-EPLST Engine Type 3-cylinder diesel 3-cylinder, liquid-cooled, diesel, naturally aspirated, DI No. of Cylinders 3 3 Displacement 80.4 in³ 100.2 in³ Rated Engine Speed 2700 rpm 2400 rpm Engine Power (Gross) 24.4 hp 24.4 hp PTO Power 18.5 hp 19 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Single replaceable dry element Dry Fuel System Not Published DI (direct injection) Alternator 50 A 55 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump Implement Flow 6.7 gpm 6.1 gpm Steering Flow 2.9 gpm 4.6 gpm Total Hydraulic Flow 9.6 gpm (6.7 + 2.9, computed) 10.7 gpm Overall Hydraulic Pump Flow 9.6 gpm (6.7 + 2.9, computed) 10.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 pair No. of Optional Remote Valves One (DIA, optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 11.4 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Standard, 2000 rpm Available (option) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,433 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,058 lb 1,433 lb Lift Control Type Chain-type stabilizers, fixed link ends Position control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic (HST), dual pedal HST No. of Speeds HST, 2 ranges 3 ranges Max Travel Speed (Forward) 11.3 mph (HST, R4 tires) Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock (foot pedal) Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Mechanical wet multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Four-wheel drive (standard) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 49.1 in (with R4 tires) 66 in Wheelbase 59 in 69 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 11.5 ft (3.5 m) Height to Top of ROPS 85.5 in (with R4 tires) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 90 in Overall Length 103.6 in (with R4 tires) 125 in (frame to link) ▶ WeightTractor Weight (Base) 1,708 lb 3,609 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 turf tread or R4 industrial tread Ag, Industrial, VT and Turf; VT same size as Industrial R1 Agricultural - Front Not Published 7-14 R1 Agricultural - Rear Not Published 11.2-24 R3 Turf - Front 23x8.50-12 25x8.50-14 R3 Turf - Rear 33x12-16.5 41x14.00-20 R4 Industrial - Front 23x8.50-12 27x8.50-15 R4 Industrial - Rear 12-16.5 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LL3002: ISO 24410 Quick Attaching Coupler Loader Model 235TL LL3002 Loader Lift Height 235TL: 80.7 in (at pivot pin) LL3002: 94.3 in Loader Lift Capacity (Full Height) 235TL: 1,034 lb LL3002: 1,599 lb (at pivot pin, maximum height) Loader Breakout Force 235TL: 1,672 lb LL3002: 2,962 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years; powertrain 3 years (5 years total) Two-year bumper to bumper; six-year limited powertrain
