▶ EngineEngine Manufacturer Mitsubishi Yanmar Engine Model S3L2 3TNV80F Engine Type 3-cylinder diesel 3-cylinder, naturally aspirated, liquid-cooled diesel No. of Cylinders 3 3 Displacement 80.4 in³ 77.3 in³ Rated Engine Speed 2700 rpm 3000 rpm Engine Power (Gross) 24.4 hp 24.7 hp PTO Power 18.5 hp 17.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Pressurized liquid with recirculating bypass Air Cleaner Single replaceable dry element Single-element dry air cleaner Fuel System Not Published In-line injection pump, indirect injection (swirl chamber) Alternator 50 A 40 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow 6.7 gpm 4.6 gpm Steering Flow 2.9 gpm 2.1 gpm Total Hydraulic Flow 9.6 gpm (6.7 + 2.9, computed) 6.7 gpm Overall Hydraulic Pump Flow 9.6 gpm (6.7 + 2.9, computed) 6.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves 1 (DIA, optional) 1 ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity Not Published 3.49 qt Crankcase Capacity Not Published 3 qt Transmission / Hydraulic System Capacity Not Published 3.3 gal Front Axle Fluid Capacity Not Published 0.5 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard, 2000 rpm Standard (2,500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,433 lb 992 lb Hitch Lift Capacity (at 24”) 1,058 lb 728 lb Lift Control Type Chain-type stabilizers, fixed link ends Lift-hold-lower ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic (HST), dual pedal 2-range hydrostatic, dual pedal No. of Speeds HST, 2 ranges Infinite (2 ranges) Max Travel Speed (Forward) 11.3 mph (HST, R4 tires) 9.1 mph Max Travel Speed (Reverse) Not Published 5.5 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock (foot pedal) Mechanical, foot-operated rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical wet multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Deluxe high-back seat with armrests and adjustable backrest Front Axle Type Four-wheel drive (standard) 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 103.6 in 97.4 in Overall Width 49.1 in 46.7 in Wheelbase 59 in 56.1 in Ground Clearance Not Published 12 in Min. Turn Radius without Brakes Not Published 94 in Height to Top of ROPS 85.5 in 90 in Height to Top of ROPS (folded) Not Published 64 in Height to Top of Cab Model Not Published 87.4 in ▶ WeightTractor Weight (Base) 1,832 lb ROPS: 1,444 lb; Cab: 1,805 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 turf tread or R4 industrial tread R3 Turf, R4 Industrial R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 23x8.50-12 18x8.50-10 R3 Turf - Rear 33x12-16.5 26x12.0-12 R4 Industrial - Front 23x8.50-12 18x8.50-10 R4 Industrial - Rear 12-16.5 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 100LC: Quick Mount system, no tools needed Loader Model 235TL 100LC Loader Lift Height 235TL: 80.7 in 100LC: 72 in Loader Lift Capacity (Full Height) 235TL: 1,034 lb 100LC: 1,005 lb Loader Breakout Force 235TL: 1,672 lb 100LC: 2,078 lb ▶ WarrantyWarranty Length & Coverage Boomer Guard 5 Limited Warranty: 5 years (2 years bumper-to-bumper plus 3 years powertrain) Boomer Guard6 limited warranty: 2 years or 750 hours full coverage plus powertrain coverage to 6 years or 1,500 hours total
