▶ EngineEngine Manufacturer LS Mtron TYM Engine Model L3CRV-T5 A1700N4-BUTR_4 Engine Type 3-cylinder, turbocharged, liquid-cooled diesel Vertical, 4-stroke, water-cooled diesel No. of Cylinders 3 3 Displacement 114.7 in³ 104.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power Gear: 29.7 hp; HST: 28 hp 29.5 hp Engine Emissions Constraints Tier 4B (final) EPA Final Tier4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Replaceable primary and inner elements Not Published Fuel System Electronically controlled common rail direct injection Not Published Alternator 70 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Gear Not Published Implement Flow 8.2 gpm 8.2 gpm Steering Flow Gear: 4.2 gpm; HST: 5.3 gpm 4.4 gpm Total Hydraulic Flow Gear: 12.4 gpm; HST: 13.5 gpm 12.6 gpm Overall Hydraulic Pump Flow Gear: 12.4 gpm; HST: 13.5 gpm 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves Up to 2 (second valve optional) Up to 2 ▶ Fluid CapacityFuel Tank Capacity 10.5 gal 7.13 gal Coolant Capacity 7.5 qt 1.32 gal Crankcase Capacity 5.8 qt 1.14 gal Transmission / Hydraulic System Capacity 8.5 gal 9.77 gal Front Axle Fluid Capacity 6.87 qt 1.69 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard (2000 rpm) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 3,307 lb Hitch Lift Capacity (at 24”) 1,345 lb 2,425 lb Lift Control Type Position control (draft control optional) Position control ▶ Transmission & DrivetrainTransmission Type Gear: 12x12 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal Hydrostatic (HST), 3-range No. of Speeds Gear: 12F/12R; HST: 3-range 3 range (HST) Max Travel Speed (Forward) Gear: 14.2 mph; HST: 14.8 mph 19.08 mph Max Travel Speed (Reverse) Gear: 13.63 mph; HST: 13.60 mph 19.08 mph Clutch Gear: dry single disc (9.4 in); HST: n/a None (HST) Differential Lock & Limited Slip Options Mechanical rear differential lock (pedal) Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet multi-disc Wet, multi-disc Seat Suspension & Adjustability Adjustable suspension seat (fore/aft, weight and height adjustment) Not Published Front Axle Type Four-wheel drive (FWD) Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 66.4 in 56.7 in Wheelbase 66 in 65.7 in Ground Clearance Not Published 13.1 in Min. Turn Radius without Brakes 9.2 ft (with brake applied) Not Published Height to Top of ROPS 92.7 in 96.85 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 119 in 134.88 in ▶ WeightTractor Weight (Base) Gear: 2,804 lb; HST: 2,870 lb 3,164 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 ag 8.0-16 / 12.4-24 (standard); R4 industrial 28x8.50-15 / 43x16.00-20 R1 Agricultural - Front 7-14 8.0-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front 25x8.50-14 Not Published R3 Turf - Rear 41x14.00-20 Not Published R4 Industrial - Front 25x8.50-14 28x8.50-15 R4 Industrial - Rear 43x16.00-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Tool-free loader mount; optional skid-steer quick-attach plates SSQA Loader Model 250TLA BBL400 Loader Lift Height 250TLA: 104 in (at pivot pin) 104 in Loader Lift Capacity (Full Height) 250TLA: 1,822 lb (at bucket pivot pin, max height) 2,200 lb (at pivot pin) Loader Breakout Force 250TLA: 3,257 lb (at bucket pivot pin) 3,660 lb ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total) Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
