▶ EngineEngine Manufacturer LS Mtron LS Engine Model L3CRV-T4 L3C19-T4 Engine Type 3-cylinder, turbocharged, liquid-cooled diesel 3-cylinder, liquid-cooled, diesel, turbocharged (TC), CRDI No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power Gear: 34 hp; HST: 32 hp 34 hp Engine Emissions Constraints Tier 4B (final) Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Replaceable primary and inner elements Dry Fuel System Electronically controlled common rail direct injection CRDI (Delphi common rail direct injection) Alternator ROPS: 70 A, 12 V; Cab: 85 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear Gear pump, engine driven Implement Flow 8.2 gpm 8.2 gpm Steering Flow Gear: 4.2 gpm; HST: 5.3 gpm 4.1 gpm Total Hydraulic Flow Gear: 12.4 gpm; HST: 13.5 gpm 12.3 gpm Overall Hydraulic Pump Flow Gear: 12.4 gpm; HST: 13.5 gpm 12.3 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 None No. of Optional Remote Valves Up to 2 (second valve optional) 1 or 2 pairs (optional) ▶ Fluid CapacityFuel Tank Capacity ROPS: 10.5 gal; Cab: 12.4 gal 7.4 gal Coolant Capacity 7.5 qt 1.9 gal Crankcase Capacity 5.8 qt 1.5 gal Transmission / Hydraulic System Capacity 8.5 gal 8.5 gal Front Axle Fluid Capacity 6.87 qt 1.7 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent (wet disc clutch) PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Standard (2000 rpm) Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,345 lb 1,433 lb Lift Control Type Position control (draft control optional) Position control ▶ Transmission & DrivetrainTransmission Type Gear: 12x12 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal Synchro Shuttle No. of Speeds Gear: 12F/12R; HST: 3-range F12 x R12 Max Travel Speed (Forward) Gear: 14.2 mph; HST: 14.8 mph 14.33 mph Max Travel Speed (Reverse) Gear: 13.63 mph; HST: 13.60 mph 13.63 mph Clutch Gear: dry single disc (9.4 in); HST: n/a Dry single clutch Differential Lock & Limited Slip Options Mechanical rear differential lock (pedal) Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet multi-disc Wet, multi-disc Seat Suspension & Adjustability ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth seat with weight control, easy fore/aft movement and adjustable armrests Not Published Front Axle Type Four-wheel drive (FWD) Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 66.4 in 54 in Wheelbase 66 in 69 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 9.2 ft (with brake applied) 10.79 ft (left); 11.02 ft (right) Height to Top of ROPS 92.7 in 88 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 90 in Not Published Overall Length 119 in 121 in (frame to link) ▶ WeightTractor Weight (Base) ROPS Gear: 2,804 lb; ROPS HST: 2,870 lb; Cab: 3,574 lb 2,881 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Ag, industrial or turf tires at no additional cost R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25x8.50-14 25x8.50-14 R3 Turf - Rear 41x14.00-20 41x14-20 R4 Industrial - Front 25x8.50-14 27x8.50-14 R4 Industrial - Rear 43x16.00-20 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Tool-free loader mount; optional skid-steer quick-attach plates Not Published Loader Model 250TLA LL3302 Loader Lift Height 250TLA: 104 in (at pivot pin) LL3302: 94 in Loader Lift Capacity (Full Height) 250TLA: 1,822 lb (at bucket pivot pin, max height) LL3302: 2,153 lb (at pivot pin, full height) Loader Breakout Force 250TLA: 3,257 lb (at bucket pivot pin) LL3302: 3,579 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total) 6-year limited warranty
