▶ EngineEngine Manufacturer LS Mtron LS Mtron Engine Model L3CRV-T8 Not Published Engine Type 3-cylinder, turbocharged, liquid-cooled diesel Diesel, 3-cylinder, turbocharged No. of Cylinders 3 3 Displacement 114.7 in³ 115.9 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 50 hp 50 hp PTO Power Gear: 42.5 hp; HST: 40 hp 40 hp Engine Emissions Constraints Tier 4B (final) Tier 4 Cooling System Type Liquid cooled Not Published Air Cleaner Replaceable primary and inner elements Not Published Fuel System Electronically controlled common rail direct injection Common rail direct injection Alternator ROPS: 70 A; Cab: 85 A Not Published ▶ HydraulicsPump Type Gear Not Published Implement Flow 8.2 gpm 8.2 gpm Steering Flow Gear: 4.2 gpm; HST: 5.3 gpm Not Published Total Hydraulic Flow Gear: 12.4 gpm; HST: 13.5 gpm 13.5 gpm (8.2 + 5.3, computed) Overall Hydraulic Pump Flow Gear: 12.4 gpm; HST: 13.5 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Up to 2 (second valve optional) 2 ▶ Fluid CapacityFuel Tank Capacity ROPS: 10.5 gal; Cab: 12.4 gal Non-cab: 10.5 gal; Cab: 12.4 gal Coolant Capacity 2.3 gal Not Published Crankcase Capacity 5.8 qt Not Published Transmission / Hydraulic System Capacity 11.4 gal Not Published Front Axle Fluid Capacity 2.2 gal Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent rear PTO, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard (2000 rpm) Optional, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,756 lb Not Published Hitch Lift Capacity (at 24”) 2,116 lb 2,756 lb Lift Control Type Position control (draft control optional) Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type Gear: 16x16 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal 3-range hydrostatic (HST) No. of Speeds Gear: 16F/16R; HST: 3-range Infinitely variable, 3 ranges Max Travel Speed (Forward) Gear: 17.0 mph; HST: 17.9 mph Not Published Max Travel Speed (Reverse) Gear: 15.3 mph; HST: 11.37 mph Not Published Clutch Gear: dry single disc (10.8 in); HST: n/a Not Applicable Differential Lock & Limited Slip Options Mechanical rear differential lock (pedal) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Not Published Brakes Wet multi-disc Not Published Seat Suspension & Adjustability ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth suspension seat with weight control, fore/aft adjustment and adjustable armrests Adjustable suspension seat Front Axle Type Four-wheel drive (FWD) Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Short position: 2,317 lb; Regular position: 1,598 lb; Extended position: 1,091 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 69.1 in Not Published Wheelbase 73.2 in 73.2 in Ground Clearance 15 in Not Published Min. Turn Radius without Brakes 111.8 in (right turn); 123.2 in (left turn) (with brake applied) Not Published Height to Top of ROPS 97.1 in 97.1 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model 94 in Not Applicable Overall Length 128.1 in 128.1 in ▶ WeightTractor Weight (Base) ROPS Gear: 3,424 lb; ROPS HST: 3,490 lb; Cab: 4,194 lb Non-cab: 3,770 lb; Cab: 4,453 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 9.5-16 Not Published R1 Agricultural - Rear 13.6-24 Not Published R3 Turf - Front 28x8.50-15 Not Published R3 Turf - Rear 41x14.00-20 Not Published R4 Industrial - Front 12x16.5 Not Published R4 Industrial - Rear 17.5Lx24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Tool-free loader mount; optional skid-steer quick-attach plates Quick-Attach faceplate Loader Model 260TLA L360A Loader Lift Height 260TLA: 109 in (at pivot pin) 112 in Loader Lift Capacity (Full Height) 260TLA: 2,371 lb (at bucket pivot pin, max height) 1,830 lb at 31.5 in. forward of pivot pin (L360A) Loader Breakout Force 260TLA: 4,081 lb (at bucket pivot pin) 3,114 lbf ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total) Basic 2 years; powertrain 4 additional years
