▶ EnginePTO Power 40 hp 44.2 hp Alternator 70 A, 12 V 70 A, 12 V Air Cleaner Not Published Dry Engine Type Water-cooled, 4-stroke common rail turbocharged diesel 3-Cylinder, liquid-cooled, Diesel, TC, CRDI Fuel System High pressure common rail (ECU controlled) CRDI Displacement 0.1 in³ 114.7 in³ No. of Cylinders 3 3 Rated Engine Speed 2600 rpm 2600 rpm Cooling System Type Pressurized liquid w/ recirculating bypass Liquid-cooled Engine Manufacturer LS Mtron LS Mtron Engine Power (Gross) 52.8 hp @ 600 rpm 52 hp Engine Emissions Constraints Tier 4B Final Tier 4 ▶ WeightWeight with ROPS and Loader Not Published 4,649 lb Weight with Cab and Loader Not Published 5,160 lb ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain, 2-year full coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty ▶ HydraulicsPump Type Gear Gear pump, engine drive Steering Flow HST: 6.3 gpm; Gear: 4.2 gpm MEC: 4.1 gpm; C-HST: 6.2 gpm; S-HST: 6.9 gpm Implement Flow 8.5 gpm 8.2 gpm Total Hydraulic Flow HST: 14.8 gpm; Gear: 12.7 gpm MEC: 12.3 gpm; C-HST: 14.4 gpm; S-HST: 15.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow HST: 14.8 gpm; Gear: 12.7 gpm MEC: 12.3 gpm; C-HST: 14.4 gpm; S-HST: 15.1 gpm No. of Optional Remote Valves 1 3 Pair (2 Detent, 1 STD) No. of Standard Remote Valves 1 2 Pair (1 Detent, 1 STD) ▶ PTO & HitchPTO Rear 540 rpm 540 rpm PTO Type Independent, electro-hydraulic engagement Independent PTO with wet disk clutch Lift Control Type Position control Position & Draft Hitch Lift Capacity 2,756 lb 2,755 lb Mid-PTO Availability Optional Optional (2,000 rpm) Category, 3-Point Hitch Category I Category II Hitch Lift Capacity (at 24”) 2,469 lb 2,469 lb ▶ Tire OptionsR3 Turf - Rear 41X14.00-20 41X14-20 R3 Turf - Front 28X8.50-15 28X8.50-15 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 17.5LX24 4.6 gal-24 R4 Industrial - Front 12X16.5 12-16.5 R1 Agricultural - Rear 13.6-24 13.6-24 R1 Agricultural - Front 9.5-16 9.5-16 ▶ Fluid CapacityCoolant Capacity 2.3 gal 2.3 gal Crankcase Capacity 5.8 qt 1.6 gal Fuel Tank Capacity 11.0 gal Cabin: 12.4 gal; ROPS: 10.6 gal Front Axle Fluid Capacity 2.2 gal 2.2 gal Transmission / Hydraulic System Capacity 11.4 gal 11.4 gal ▶ Loader & AttachmentsLoader Lift Height 109 in 94.4 in Loader Breakout Force 4,081 lb 4,063 lb Quick Attach Loader System 260TLA: New Holland Quick Mount; optional skid steer quick attach plates LL4106: 2 Lever Skid Steer Coupler (allows for universal skid steer attachments) Loader Lift Capacity (Full Height) 2,371 lb 2,680 lb ▶ Transmission & DrivetrainClutch HST: Not Applicable; Gear: Dry disc Power clutch valve & lever No. of Speeds HST: 3-range; Gear: 16F/16R Gear: F16 x R16 Transmission Type HST: 3-range hydrostatic; Gear: 16x16 Synchro shuttle / Powerclutch Max Travel Speed (Forward) HST: 15.63 mph; Gear: 16.8 mph Not Published Max Travel Speed (Reverse) HST: 11.37 mph; Gear: 15.3 mph Not Published Differential Lock & Limited Slip Options Differential lock Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsBrakes Wet disc Wet, Multi-disc Steering Power steering Hydrostatic Power Steering Frame Type Not Published Not Published Front Axle Type 4WD (FWD) Not Published Drawbar Capacity Short: 2,317 lb; Regular: 1,598 lb; Extend: 1,091 lb Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 73 in 73.2 in Overall Width 63 in 62.5 in Ground Clearance 15 in Not Published Height to Top of ROPS 96 in 95 in Height to Top of Cab Model 91 in 90 in Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published 10.3 ft (3.1 m) Overall Length with 3-Point Hitch 142 in 133 in
