▶ EngineEngine Manufacturer LS Mtron Daedong Engine Model LS Mtron L3C19-T 3HT-TH4C Engine Type Water-cooled, 4-stroke common rail turbocharged diesel Turbocharged diesel No. of Cylinders 3 3 Displacement 114.7 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2750 rpm Engine Power (Gross) 57.8 hp @ 600 rpm 57.7 hp PTO Power 44 hp 45.1 hp Engine Emissions Constraints Tier 4B Final Tier 4 Cooling System Type Pressurized liquid w/ recirculating bypass Liquid-cooled Air Cleaner Not Published Not Published Fuel System High pressure common rail (ECU controlled) Not Published Alternator 70 A, 12 V Not Published ▶ HydraulicsPump Type Gear Not Published Implement Flow 8.5 gpm 9.6 gpm Steering Flow HST: 6.3 gpm; Gear: 4.2 gpm 6.9 gpm Total Hydraulic Flow HST: 14.8 gpm; Gear: 12.7 gpm 16.5 gpm Overall Hydraulic Pump Flow HST: 14.8 gpm; Gear: 12.7 gpm 16.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 pair No. of Optional Remote Valves 1 1 pair (2nd pair optional) ▶ Fluid CapacityFuel Tank Capacity 11.0 gal 11.9 gal Coolant Capacity 2.3 gal Not Published Crankcase Capacity 5.8 qt Not Published Transmission / Hydraulic System Capacity 11.4 gal Not Published Front Axle Fluid Capacity 2.2 gal Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional Optional: 2119 rpm Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity 2,756 lb 2716 lb Hitch Lift Capacity (at 24”) 2,469 lb 2716 lb Lift Control Type Position control Hydraulic Position Control System ▶ Transmission & DrivetrainTransmission Type HST: 3-range hydrostatic; Gear: 16x16 3-Range HST No. of Speeds HST: 3-range; Gear: 16F/16R Infinite forward and reverse (3-range) Max Travel Speed (Forward) HST: 15.63 mph; Gear: 16.8 mph 18.0 mph Max Travel Speed (Reverse) HST: 11.37 mph; Gear: 15.3 mph 12.6 mph Clutch HST: Not Applicable; Gear: Dry disc Not Published Differential Lock & Limited Slip Options Differential lock Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc Wet multi-disc Seat Suspension & Adjustability Not Published Adjustable seat (standard) Front Axle Type 4WD (FWD) Four-wheel drive (standard) Front Axle Rating Not Published Not Published Drawbar Capacity Short: 2,317 lb; Regular: 1,598 lb; Extend: 1,091 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 142 in 125.5 in Overall Width 63 in 70.3 in Wheelbase 73 in 71.2 in Ground Clearance 15 in 15.3 in Min. Turn Radius without Brakes Not Published 116.1 in (with brake applied) Height to Top of ROPS 96 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91 in 94.3 in ▶ WeightTractor Weight (Base) Not Published 4300 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Not Published R1 Agricultural - Front 9.5-16 8-16 R1 Agricultural - Rear 13.6-24 13.6-24 R3 Turf - Front 28X8.50-15 Not Published R3 Turf - Rear 41X14.00-20 Not Published R4 Industrial - Front 12X16.5 Not Published R4 Industrial - Rear 17.5LX24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System 260TLA: New Holland Quick Mount; optional skid steer quick attach plates Front-end loader with standard quick attach mounting system Loader Model Not Published FL9 Loader Lift Height 109 in 103.2 in Loader Lift Capacity (Full Height) 2,371 lb 1795 lb Loader Breakout Force 4,081 lb Not Published ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain, 2-year full coverage 24 months or 1500 hours (whichever occurs first); powertrain 48 months (consumer use) or 36 months / 2000 hours (business use) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
