▶ EngineEngine Manufacturer LS Mtron KIOTI (Daedong) Engine Model LS Mtron L3C19-T 3HT-S4TM58A Engine Type Water-cooled, 4-stroke common rail turbocharged diesel KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI No. of Cylinders 3 3 Displacement 114.7 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 57.8 hp @ 600 rpm 57.7 hp PTO Power 44 hp 47.9 hp Engine Emissions Constraints Tier 4B Final Tier 4 Cooling System Type Pressurized liquid w/ recirculating bypass Water-cooled Air Cleaner Not Published Dry type element Fuel System High pressure common rail (ECU controlled) Common Rail Direct Injection (CRDI) Alternator 70 A, 12 V Not Published ▶ HydraulicsPump Type Gear Gear Implement Flow 8.5 gpm Not Published Steering Flow HST: 6.3 gpm; Gear: 4.2 gpm Not Published Total Hydraulic Flow HST: 14.8 gpm; Gear: 12.7 gpm 16.5 gpm Overall Hydraulic Pump Flow HST: 14.8 gpm; Gear: 12.7 gpm 16.5 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 11.0 gal 13.2 gal Coolant Capacity 2.3 gal 2.03 gal Crankcase Capacity 5.8 qt 1.95 gal Transmission / Hydraulic System Capacity 11.4 gal 9.51 gal Front Axle Fluid Capacity 2.2 gal 2.25 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional Optional (2,000 rpm) Category, 3-Point Hitch Category I Category II Hitch Lift Capacity 2,756 lb 2,940 lb Hitch Lift Capacity (at 24”) 2,469 lb 2,493 lb Lift Control Type Position control Position with Draft Control ▶ Transmission & DrivetrainTransmission Type HST: 3-range hydrostatic; Gear: 16x16 Hydrostatic No. of Speeds HST: 3-range; Gear: 16F/16R 3-Range Max Travel Speed (Forward) HST: 15.63 mph; Gear: 16.8 mph 17.5 mph Max Travel Speed (Reverse) HST: 11.37 mph; Gear: 15.3 mph 12.2 mph Clutch HST: Not Applicable; Gear: Dry disc Not Published Differential Lock & Limited Slip Options Differential lock Mechanical differential lock: rear standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Power Steering Brakes Wet disc Wet disc type Seat Suspension & Adjustability Not Published Deluxe suspension seat Front Axle Type 4WD (FWD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Short: 2,317 lb; Regular: 1,598 lb; Extend: 1,091 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 142 in 136.4 in Overall Width 63 in 70.4 in Wheelbase 73 in 75.5 in Ground Clearance 15 in 11.8 in Min. Turn Radius without Brakes Not Published 11.2 ft (with brake applied) Height to Top of ROPS 96 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91 in 93.7 in ▶ WeightTractor Weight (Base) Not Published 4,479 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 8-16 R1 Agricultural - Rear 13.6-24 13.6-24 R3 Turf - Front 28X8.50-15 29-12.5-15 R3 Turf - Rear 41X14.00-20 21.5L-16.1 R4 Industrial - Front 12X16.5 10-16.5 R4 Industrial - Rear 17.5LX24 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System 260TLA: New Holland Quick Mount; optional skid steer quick attach plates Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model Not Published KL5810 Loader Lift Height 109 in KL5810: 106.3 in (to pivot pin) Loader Lift Capacity (Full Height) 2,371 lb KL5810: 2,621 lb (at pivot pin, max height) Loader Breakout Force 4,081 lb KL5810: 3,896 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain, 2-year full coverage Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
