▶ EngineEngine Manufacturer FPT John Deere Engine Model F36 PowerTech PWL 4045 Engine Type 4-cylinder diesel, turbocharged and aftercooled Diesel, turbocharged, aftercooled No. of Cylinders 4 4 Displacement 219.7 in³ 276 in³ Rated Engine Speed 2300 rpm 2400 rpm Engine Power (Gross) 99.2 hp 100 hp PTO Power Not Published 85 hp Engine Emissions Constraints Stage V (ECOBlue Compact HI-eSCR + Light CEGR) Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Dry type with safety element Fuel System Common rail fuel injection High Pressure Common Rail Alternator Not Published OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering pump Tandem gear pump (implement + steering) Implement Flow 21.7 gpm 15.9 gpm Steering Flow 9.7 gpm 6.6 gpm Total Hydraulic Flow 31.4 gpm (21.7 + 9.7, computed) 22.5 gpm Overall Hydraulic Pump Flow 31.4 gpm (21.7 + 9.7, computed) 22.5 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear remotes (four couplers) 2 No. of Optional Remote Valves 1 (3rd rear remote); 1 with diverter (3rd rear remote with 1 diverter) 3 ▶ Fluid CapacityFuel Tank Capacity 34.3 gal OOS: 25 gal; Cab: 30 gal Coolant Capacity Not Published Cab: 3 gal; OOS: 2.5 gal Crankcase Capacity Not Published 3.2 gal (with filter) Transmission / Hydraulic System Capacity Not Published 11.5 gal Front Axle Fluid Capacity Not Published MFWD differential housing: 1.3 gal; MFWD wheel hub (each): 0.74 qt ▶ PTO & HitchPTO Type Fully independent electrohydraulic PTO, wet clutch Independent, electrohydraulic engagement PTO Rear 540/1000 rpm (interchangeable, standard) 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,123 lb 4,630 lb Lift Control Type 12x12 models: mechanical draft control; Dual Command models: electronic draft control; single-lever Lift-O-Matic PLUS (standard) Top link draft sensing; mechanical hitch controls ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (column-mounted) PowrReverser No. of Speeds 12F/12R; 20F/20R with creeper; 24F/24R Dual Command 12F/12R (standard); 24F/12R (optional) Max Travel Speed (Forward) 25 mph 12F/12R: 21.7 mph; 24F/12R: 24.9 mph (electronically limited) Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Wet traction clutch Differential Lock & Limited Slip Options Electrohydraulic rear differential lock Pedal-operated differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Hydrostatic power steering Brakes Not Published Hydraulic wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Air-suspension cloth seat Not Published Front Axle Type Heavy-duty class 1.5 4WD front axle Mechanical front wheel drive (MFWD) Front Axle Rating Not Published 6,615 lb Drawbar Capacity Not Published Standard: 2,755 lb; 2,425 lb (350 and 15.7 in extended). Heavy-Duty: 3,195 lb; 2,645 lb (350 and 15.7 in extended) ▶ Dimensions & ManeuverabilityOverall Width 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) Not Published Wheelbase 92.5 in 92.5 in Ground Clearance Not Published ROPS: 17 in; Cab: 15.2 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 100.8 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model 103.6 in 101.2 in Overall Length 158.2 in 159.13 in ▶ WeightTractor Weight (Base) 10,240 lb OOS: 7,275 lb (shipping weight); Cab: 8,150 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 420/85R38 (reference tire for weight and dimensions); rear tires as large as R38 available Not Published R1 Agricultural - Front Not Published 12.4-24 R1 Agricultural - Rear Not Published 18.4-30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (available, both LU loaders) 520M; 540M Loader Model 650LU (NSL); 655LU (MSL) 520M and 540M (previously H240 and H260) Loader Lift Height 650LU: 149.7 in; 655LU: 149.7 in (max lift height to pivot pin) 520M MSL: 132.0 in Loader Lift Capacity (Full Height) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) 520M MSL: 2,606 lb (to maximum height, measured at pivot) Loader Breakout Force Not Published 520M MSL: 4,793 lb (measured at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
