▶ EngineEngine Manufacturer FPT AGCO Power Engine Model F36 33 AWI HD Engine Type 4-cylinder diesel, turbocharged and aftercooled 3-cylinder turbocharged and intercooled diesel No. of Cylinders 4 3 Displacement 219.7 in³ 201 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 99.2 hp 100 hp PTO Power Not Published 75 hp Engine Emissions Constraints Stage V (ECOBlue Compact HI-eSCR + Light CEGR) Tier 4i Cooling System Type Not Published Water-cooled Air Cleaner Not Published 2-stage dry Fuel System Common rail fuel injection Common rail direct injection Alternator Not Published 120 A ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering pump Single gear pump; tandem gear pumps optional Implement Flow 21.7 gpm 15 gpm standard; 26 gpm with optional Twin Flow Steering Flow 9.7 gpm Not Published Total Hydraulic Flow 31.4 gpm (21.7 + 9.7, computed) 26 gpm (tandem pumps: 15 gpm to the 3-point hitch plus 11 gpm to remotes, combinable) Overall Hydraulic Pump Flow 31.4 gpm (21.7 + 9.7, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 15 gpm standard; 26 gpm with optional Twin Flow No. of Standard Remote Valves 2 rear remotes (four couplers) 2 No. of Optional Remote Valves 1 (3rd rear remote); 1 with diverter (3rd rear remote with 1 diverter) Up to 4 ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 42 gal Coolant Capacity Not Published 15.3 qt Crankcase Capacity Not Published 13.7 qt Transmission / Hydraulic System Capacity Not Published 17.2 gal Front Axle Fluid Capacity Not Published 5.3 qt axle beam; 0.85 qt each final drive ▶ PTO & HitchPTO Type Fully independent electrohydraulic PTO, wet clutch Independent, electro-hydraulic engagement and speed selection PTO Rear 540/1000 rpm (interchangeable, standard) 540/540E standard; 540/540E/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 9,480 lb Hitch Lift Capacity (at 24”) 4,123 lb 7,100 lb Lift Control Type 12x12 models: mechanical draft control; Dual Command models: electronic draft control; single-lever Lift-O-Matic PLUS (standard) Electronically operated, lower-link draft sensing ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (column-mounted) Dyna-4 16x16 power shift and power shuttle (AUTO-DRIVE optional, 14:1 creeper optional) No. of Speeds 12F/12R; 20F/20R with creeper; 24F/24R Dual Command 16F / 16R Max Travel Speed (Forward) 25 mph 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Wet multi-disc, foot pedal and electronic control Differential Lock & Limited Slip Options Electrohydraulic rear differential lock Fully locking front and rear axle differentials, electro-hydraulically engaged ▶ Chassis, Steering & ControlsFrame Type Not Published Rigid structural chassis; solid cast-steel flanged rear axle, internal planetary reduction Steering Not Published Hydrostatic power steering Brakes Not Published Internal wet disc, hydraulic power assist, individual left and right foot pedals Seat Suspension & Adjustability Air-suspension cloth seat Mechanical suspended swivel seat, standard; manual or automatic air-suspension, optional Front Axle Type Heavy-duty class 1.5 4WD front axle Adjustable 2WD, or fixed cast-steel 4WD (single-piece), outboard planetary final drives Front Axle Rating Not Published 2WD: 6,085 lb; 4WD: 10,500 lb Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) 79.3 in Wheelbase 92.5 in 97.1 in Ground Clearance Not Published 17.6 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.6 in 111.3 in (16.9R38 rear tires) Overall Length 158.2 in 167.5 in ▶ WeightTractor Weight (Base) 10,240 lb 2WD: 8,426 lb; 4WD: 8,978 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 420/85R38 (reference tire for weight and dimensions); rear tires as large as R38 available R1 radial agricultural tires only; 16.9R38 rear is the speed chart basis (16.9R34, 16.9R30, 18.4R30, 18.4R34, 13.6R38 listed) R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published 16.9R38 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (available, both LU loaders) MF931, MF941, MF946: quick attachment, single lever locking system Loader Model 650LU (NSL); 655LU (MSL) MF931, MF941, MF946 Loader Lift Height 650LU: 149.7 in; 655LU: 149.7 in (max lift height to pivot pin) MF931: 138 in; MF941: 148 in; MF946: 148 in (at pivot pins) Loader Lift Capacity (Full Height) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) MF931: 3,880 lb; MF941: 4,735 lb; MF946: 3,965 lb (at pivot) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published 2-year/2,000-hour full coverage, all parts and labor
