▶ EngineEngine Manufacturer FPT AGCO Power Engine Model F36 44 AWFC Engine Type 4-cylinder diesel, turbocharged and aftercooled 4-cylinder, intercooled turbocharged, liquid-cooled diesel No. of Cylinders 4 4 Displacement 219.7 in³ 268.5 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 99.2 hp 100 hp PTO Power Not Published Power Shuttle: 83 hp; Dyna-4: 76 hp Engine Emissions Constraints Stage V (ECOBlue Compact HI-eSCR + Light CEGR) Tier 4 Cooling System Type Not Published Liquid cooled Air Cleaner Not Published Not Published Fuel System Common rail fuel injection High-pressure common-rail direct injection (HPCR) Alternator Not Published 80 A, 12 V ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering pump Two high-pressure gear pumps Implement Flow 21.7 gpm 15.1 gpm Steering Flow 9.7 gpm Not Published Total Hydraulic Flow 31.4 gpm (21.7 + 9.7, computed) 26 gpm Overall Hydraulic Pump Flow 31.4 gpm (21.7 + 9.7, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 26 gpm No. of Standard Remote Valves 2 rear remotes (four couplers) 2 No. of Optional Remote Valves 1 (3rd rear remote); 1 with diverter (3rd rear remote with 1 diverter) 1 ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 38.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully independent electrohydraulic PTO, wet clutch Independent, electro-hydraulic engagement via switch PTO Rear 540/1000 rpm (interchangeable, standard) 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,123 lb 7,710 lb Lift Control Type 12x12 models: mechanical draft control; Dual Command models: electronic draft control; single-lever Lift-O-Matic PLUS (standard) Cab: electric controlled 3-point linkage with draft control; Platform: lever controlled 3-point linkage with draft control ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (column-mounted) Power Shuttle: 12F x 12R, 2 ranges, electro-hydraulic shuttle; Dyna-4: 16F x 16R powershift No. of Speeds 12F/12R; 20F/20R with creeper; 24F/24R Dual Command Power Shuttle: 12 forward, 12 reverse; Dyna-4: 16 forward, 16 reverse Max Travel Speed (Forward) 25 mph 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Wet clutch with easy shift knob and electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Electrohydraulic rear differential lock Electro-hydraulic rear differential lock (rocker switch); hydraulic front differential lock on 4WD ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Cab: tilt and telescopic steering column; Platform: tilt steering column Brakes Not Published Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Air-suspension cloth seat Cab: air-suspension swivel seat; platform: mechanical spring-suspension seat with armrests Front Axle Type Heavy-duty class 1.5 4WD front axle Heavy-duty 4WD front axle, center driveline Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) 64.8 in Wheelbase 92.5 in 95.7 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.6 in Not Published Overall Length 158.2 in Not Published ▶ WeightTractor Weight (Base) 10,240 lb 4WD ROPS: 9,195 lb; 4WD Cab: 10,011 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 420/85R38 (reference tire for weight and dimensions); rear tires as large as R38 available Rear: 460/85R34 standard radial R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (available, both LU loaders) Not Published Loader Model 650LU (NSL); 655LU (MSL) 941X; 946X; FL.3723; FL.3819 Loader Lift Height 650LU: 149.7 in; 655LU: 149.7 in (max lift height to pivot pin) 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in Loader Lift Capacity (Full Height) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) 941X: 2,220 lb; FL.3723: 2,840 lb (to full height, at 31.5 in forward of pivot pin) Loader Breakout Force Not Published FL.3723: 5,819 lb; FL.3819: 4,893 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
