▶ EngineEngine Manufacturer Fiat Powertrain Technologies (FPT) FPT Engine Model F36 NEF Engine Type 4-cylinder diesel, turbocharged and aftercooled 4-cylinder, 16-valve, turbocharged and intercooled, common-rail diesel No. of Cylinders 4 4 Displacement 220 in³ 274 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 108.6 hp 110 hp PTO Power Not Published 92 hp Engine Emissions Constraints Stage V Compliant with ECOBlue Compact HI-eSCR + Light CEGR Tier 4B/Final Cooling System Type Not Published Not Published Air Cleaner Not Published Not Published Fuel System Common rail fuel injection High-pressure common rail fuel injection Alternator Not Published 120 A ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering pump Fixed-displacement pumps for steering, implement and auxiliary circuits, with a combining/diverter valve Implement Flow 21.7 gpm 13 gpm (implement pump); 9 gpm auxiliary pump standard on Plus, optional on Value Steering Flow 9.7 gpm 7 gpm Total Hydraulic Flow 31.4 gpm (21.7 + 9.7, computed) 29 gpm (with the 9 gpm auxiliary pump: standard on Plus, optional on Value) Overall Hydraulic Pump Flow 31.4 gpm (21.7 + 9.7, computed) 29 gpm (with the 9 gpm auxiliary pump: standard on Plus, optional on Value) Hydraulic System Type Open center Fixed-displacement pumps with combining/diverter valve; closed-center rear remote valves with flow control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear remotes (four couplers) Not Published No. of Optional Remote Valves 1 (3rd rear remote, optional); 3rd rear remote with 1 diverter (optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 57.5 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully-independent, electrohydraulic, wet-clutch Not Published PTO Rear 540/1000 rpm (interchangeable) 540/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II (flex link ends) Hitch Lift Capacity Not Published 3,735 lb (ASAE); 5,499 lb with one optional auxiliary lift cylinder; 7,326 lb with two Hitch Lift Capacity (at 24”) 4,123 lb (standard); 6,938 lb (with 2 aux rams, optional) Not Published Lift Control Type 12x12: mechanical draft control; Dual Command: electronic draft control Not Published ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (all available); column-mounted electronic power shuttle 8x8 synchronized power shuttle (hydraulic, left-hand) standard; 16x8 Dual Power synchronized hydraulic shuttle with Hi-Lo (premium); 10:1 creeper optional No. of Speeds 12x12, 20x20 with creeper, or 24x24 Dual Command (all available) 8F/8R (base); 16F/8R (premium Dual Power with Hi-Lo) Max Travel Speed (Forward) 25 mph 19 mph or 25 mph (25 mph 4WD only) Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Electrohydraulic differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Not Published Brakes Not Published Not Published Seat Suspension & Adjustability Air-suspension cloth seat Mechanical-suspension seat standard; air-suspension seat with swivel and full-size cushioned instructor seat optional (VisionView cab) Front Axle Type 4WD heavy-duty, class 1.5 front axle (standard) 4WD heavy-duty front axle, standard-duty Class 3 (cab and 4WD only) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) Not Published Wheelbase 92.5 in 99.2 in (4WD, Standard Duty Class 3 axle) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.6 in 110.2 in Overall Length 158.2 in 184.7 in (4WD, with front weights) ▶ WeightTractor Weight (Base) 10,240 lb 11,200 lb (shipping, 4WD, cab, flange axle); 12,192 lb (4WD, cab, bar axle) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 420/85R38 rear (reference tire for weight and dimensions); rear tires as large as R38 available 18.4-38 R1 rear with 14.9-28 R1 front (4WD) R1 Agricultural - Front Not Published 14.9-28 (4WD) R1 Agricultural - Rear Not Published 18.4-38 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (available, 650LU and 655LU) Skid steer (SSL) or Euro style attachment couplers Loader Model 650LU (NSL); 655LU (MSL) 830LA (NSL); 835LA (MSL) Loader Lift Height 650LU: 149.7 in; 655LU: 149.7 in (max lift height to pivot pin) 830LA: 150.0 in; 835LA: 150.0 in (to pivot pin) Loader Lift Capacity (Full Height) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) 830LA: 2,557 lb; 835LA: 3,813 lb (to maximum height, measured 31.5 in forward of the pivot pin) Loader Breakout Force Not Published 830LA: 3,681 lb; 835LA: 3,968 lb (measured 31.5 in forward of the pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
