▶ EngineEngine Manufacturer Fiat Powertrain Technologies (FPT) Kubota Engine Model F36 V3800-TI-CRS Engine Type 4-cylinder diesel, turbocharged and aftercooled 4-cylinder, turbocharged and intercooled, common-rail, liquid-cooled diesel No. of Cylinders 4 4 Displacement 220 in³ 230 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 115.3 hp 114.1 hp PTO Power Not Published 92 hp Engine Emissions Constraints Stage V Compliant with ECOBlue Compact HI-eSCR + Light CEGR Tier 4 Cooling System Type Not Published Liquid-cooled, pressurized radiator, recovery tank Air Cleaner Not Published 8 in dry, dual element Fuel System Common rail fuel injection Common rail direct injection Alternator Not Published 130 A, 12 V ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering pump Gear pumps Implement Flow 21.7 gpm 18.7 gpm Steering Flow 9.7 gpm 16.0 gpm Total Hydraulic Flow 31.4 gpm (21.7 + 9.7, computed) 34.7 gpm (18.7 + 16.0, computed) Overall Hydraulic Pump Flow 31.4 gpm (21.7 + 9.7, computed) Not Published Hydraulic System Type Open center Pressure compensated, fixed displacement Rear Remote Hydraulic Flow Not Published 18.7 gpm No. of Standard Remote Valves 2 rear remotes (four couplers) 2 (with built-in flow control) No. of Optional Remote Valves 1 (3rd rear remote, optional); 3rd rear remote with 1 diverter (optional) 3rd and 4th optional (4 max) ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 50.2 gal Coolant Capacity Not Published 11.3 qt Crankcase Capacity Not Published 11.3 qt Transmission / Hydraulic System Capacity Not Published 17.2 gal Front Axle Fluid Capacity Not Published 7.2 qt (differential) plus 3.8 qt per bevel gear case ▶ PTO & HitchPTO Type Fully-independent, electrohydraulic, wet-clutch Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540/1000 rpm (standard, interchangeable) 540/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 8,598 lb Hitch Lift Capacity (at 24”) 4,123 lb (standard); 6,938 lb (with 2 aux rams, optional) 6,834 lb (optional 9,447 lb) Lift Control Type 12x12: mechanical draft control; Dual Command: electronic draft control Electronic draft control, lower-link sensing; left fender-mounted hitch switch standard ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (all available); column-mounted electronic power shuttle 24F/24R powershift (8-speed main, 3-speed mechanical range, clutch button, microprocessor-controlled electro-hydraulic shuttle); 32F/32R optional with creep No. of Speeds 12x12, 20x20 with creeper, or 24x24 Dual Command (all available) 24F/24R (32F/32R with optional creep) Max Travel Speed (Forward) 25 mph 23.4 mph Max Travel Speed (Reverse) Not Published 22.33 mph (with 18.4R38 tires, at rated rpm) Clutch Not Published Multiple wet disc, electro-hydraulically operated, 5.2 in Differential Lock & Limited Slip Options Electrohydraulic differential lock Electro-hydraulic front differential lock; rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Certified ROPS cab standard Steering Not Published Hydrostatic power steering Brakes Not Published Hydraulically operated wet disc brakes with automatic front axle engagement (4WD) Seat Suspension & Adjustability Air-suspension cloth seat Air-suspension seat, swivel, reclining, fully adjustable (height, weight, fore-aft), armrests, retractable seat belt Front Axle Type 4WD heavy-duty, class 1.5 front axle (standard) 4WD, bevel-gear type, on-the-go electro-hydraulic engagement, electro-hydraulic front differential lock Front Axle Rating Not Published 6,610 lb at 62.2 in tread (9,700 lb with loader) Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) 82.7 in Wheelbase 92.5 in 95.9 in Ground Clearance Not Published 19.5 in (crop clearance) Min. Turn Radius without Brakes Not Published 13.1 ft (with Bi-Speed turn, 4WD on) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.6 in 111.8 in Overall Length 158.2 in 165.4 in ▶ WeightTractor Weight (Base) 10,240 lb 9,788 lb (with standard tire) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 420/85R38 rear (reference tire for weight and dimensions); rear tires as large as R38 available Standard: 13.6 R24 front, 18.4 R34 rear (R1 options 12.4-24, 13.6-24 front; 16.9-34, 18.4R30, 18.4-34 rear) R1 Agricultural - Front Not Published 13.6 R24 R1 Agricultural - Rear Not Published 18.4 R34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (available, 650LU and 655LU) LA1955: 2-lever quick coupler or Euro quick coupler; single-lever hydraulic quick coupler; quick attach/detach loader with boom stands, two mounting pins Loader Model 650LU (NSL); 655LU (MSL) LA1955 Loader Lift Height 650LU: 149.7 in; 655LU: 149.7 in (max lift height to pivot pin) LA1955 (height position): 145.7 in; LA1955 (power position): 132.7 in Loader Lift Capacity (Full Height) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) LA1955 (height position): 4,178 lb at pivot pin; LA1955 (power position): 4,299 lb at pivot pin Loader Breakout Force Not Published LA1955 (height position): 5,589 lbf at pivot pin; LA1955 (power position): 6,576 lbf at pivot pin ▶ WarrantyWarranty Length & Coverage Not Published Not Published
