▶ EngineEngine Manufacturer Fiat Powertrain Technologies (FPT) AGCO Power Engine Model F36 Not Published Engine Type 4-cylinder diesel, turbocharged and aftercooled 4-cylinder, turbocharged intercooled diesel No. of Cylinders 4 4 Displacement 220 in³ 268.5 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 115.3 hp 115 hp PTO Power Not Published 90 hp Engine Emissions Constraints Stage V Compliant with ECOBlue Compact HI-eSCR + Light CEGR Tier 4 Cooling System Type Not Published Liquid cooled Air Cleaner Not Published Not Published Fuel System Common rail fuel injection High-pressure common-rail direct fuel injection Alternator Not Published Platform: 80 A; Cab: 120 A ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering pump Engine-driven gear pump Implement Flow 21.7 gpm 26 gpm Steering Flow 9.7 gpm 8.5 gpm Total Hydraulic Flow 31.4 gpm (21.7 + 9.7, computed) Not Published Overall Hydraulic Pump Flow 31.4 gpm (21.7 + 9.7, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 26 gpm No. of Standard Remote Valves 2 rear remotes (four couplers) 2 No. of Optional Remote Valves 1 (3rd rear remote, optional); 3rd rear remote with 1 diverter (optional) One (3rd valve optional) ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 52.8 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully-independent, electrohydraulic, wet-clutch Independent, electrohydraulic engagement PTO Rear 540/1000 rpm (standard, interchangeable) 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 9,480 lb Hitch Lift Capacity (at 24”) 4,123 lb (standard); 6,938 lb (with 2 aux rams, optional) 7,500 lb Lift Control Type 12x12: mechanical draft control; Dual Command: electronic draft control Not Published ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (all available); column-mounted electronic power shuttle 12 x 12: 2-range power shuttle with electrohydraulic shuttle lever; Dyna-4: powershift No. of Speeds 12x12, 20x20 with creeper, or 24x24 Dual Command (all available) 12 x 12: 12F/12R; Dyna-4: 16F/16R Max Travel Speed (Forward) 25 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Multidisk wet clutch with electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Electrohydraulic differential lock Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Power steering Brakes Not Published Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Air-suspension cloth seat ROPS: mechanical spring suspension with armrests; Cab: air-ride swivel seat Front Axle Type 4WD heavy-duty, class 1.5 front axle (standard) Heavy-duty 4WD front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) Dyna-4 cab: 74.9 in; 12 x 12 cab: 79.8 in Wheelbase 92.5 in 95.7 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.6 in Not Published Overall Length 158.2 in Not Published ▶ WeightTractor Weight (Base) 10,240 lb ROPS: 9,195 lb; Cab: 10,011 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 420/85R38 rear (reference tire for weight and dimensions); rear tires as large as R38 available Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (available, 650LU and 655LU) Not Published Loader Model 650LU (NSL); 655LU (MSL) Not Published Loader Lift Height 650LU: 149.7 in; 655LU: 149.7 in (max lift height to pivot pin) Not Published Loader Lift Capacity (Full Height) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) Not Published Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
