New Holland Powerstar 120 vs New Holland T6.145 | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Rear: 3 or 4 mechanical, or 3 or 4 electro-hydraulic (Elite; 4 on Auto Command); mid-mount: 2 or 3, mechanical or electronic
Fuel Tank Capacity
34.3 gal
52.2 gal (58.6 gal with auxiliary tank); Dynamic Command: 60 gal
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Front Axle Fluid Capacity
Not Published
Not Published
PTO Type
Fully-independent, electrohydraulic, wet-clutch
Independent, direct-drive PTO with push-pull engagement and Soft Start; reversible PTO shaft
PTO Rear
540/1000 rpm (standard, interchangeable)
540/1000 rpm (540 at 1969 engine rpm, 1000 at 1893 engine rpm)
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category II
Category II (Category III/II available)
Hitch Lift Capacity
Not Published
Not Published
Hitch Lift Capacity (at 24”)
4,123 lb (standard); 6,938 lb (with 2 aux rams, optional)
Value: 8,338 lb; Auto Command: 9,214 lb; Plus, Elite and Auto Command with optional larger rams: 11,649 lb
Lift Control Type
12x12: mechanical draft control; Dual Command: electronic draft control
Electronic draft control
Transmission Type
12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (all available); column-mounted electronic power shuttle
Electro Command: 16x16 semi-powershift (standard), with 17x16 economy, 17x16 31 mph, 32x32 creeper and auto-shift options; Dynamic Command: 23x23 semi-powershift, with 24x24 economy, 31 mph and creeper options; Auto Command: continuously variable (CVT)
No. of Speeds
12x12, 20x20 with creeper, or 24x24 Dual Command (all available)
Electro Command: 16F/16R, or 17F/16R economy or high-speed, 32F/32R with creeper; Dynamic Command: 23F/23R, or 24F/24R optional; Auto Command: continuously variable
Max Travel Speed (Forward)
25 mph
25 mph (Electro Command 16x16, Dynamic Command 23x23 and Auto Command CVT standard); 31 mph (17x16 high-speed, Dynamic Command 24x24 31 mph and optional Auto Command 31 mph, FWD only); 19 mph (2WD)
Max Travel Speed (Reverse)
Not Published
Not Published
Clutch
Not Published
Not Published
Differential Lock & Limited Slip Options
Electrohydraulic differential lock
Terralock automatic traction management: automatic four-wheel drive engagement and front and rear differential locks
Frame Type
Not Published
Not Published
Steering
Not Published
Not Published
Brakes
Not Published
Wet disc
Seat Suspension & Adjustability
Air-suspension cloth seat
Standard: low-frequency suspension seat; optional: heated low-frequency suspension seat, or heated and ventilated active-suspension seat; swiveling backrest; suspended cab optional
Front Axle Type
4WD heavy-duty, class 1.5 front axle (standard)
Standard FWD axle (Class 3 and 4); optional: Terraglide suspended FWD axle or SuperSteer FWD axle; heavy-duty 2WD axle available on Electro Command
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Overall Width
56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels)
89.8 in (minimum; 91 in with 650/65R38 tires)
Wheelbase
92.5 in
Standard FWD axle: 104 in; Terraglide suspended axle: 105.7 in; SuperSteer axle: 109.8 in; 2WD: 96 in
Ground Clearance
Not Published
18.8 in (18.4R38, 520/70R38 or 600/65R38 rear tires; 16.8 in with 16.9R38, 20.8 in with 650/65R38)
Min. Turn Radius without Brakes
Not Published
15.1 ft (standard FWD axle, 55 degree turn angle); 14.1 ft (2WD or SuperSteer axle, 65 degree turn angle)
Height to Top of ROPS
Not Published
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
103.6 in
115.2 in (standard cab, 18.4R38 tires); 110.4 in (low profile cab); 117.7 in (suspended cab)
Overall Length
158.2 in
204.3 in (front linkage to rear linkage)
Tractor Weight (Base)
10,240 lb
10,560 lb (minimum shipping weight, cab FWD, less ballast)
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
420/85R38 rear (reference tire for weight and dimensions); rear tires as large as R38 available
Rear: 16.9R38, 18.4R38, 520/70R38, 600/65R38, 650/65R38 (suspended cab only), 480/70R38, 540/65R38 or 650/60R38 with matching front tires
