▶ EngineEngine Manufacturer FPT Industrial FPT Industrial Engine Model F5C F5C Engine Type 4-cylinder diesel, turbocharged and aftercooled Not Published No. of Cylinders 4 Not Published Displacement 207 in³ Not Published Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 65 hp 65 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Electronic high-pressure common rail fuel injection Not Published Alternator 120 A Not Published ▶ HydraulicsPump Type Open-center; dual pumps (implement + dedicated steering) Dual gear pumps (two separate open-center circuits) Implement Flow 12.9 gpm 9.4 gpm Steering Flow 9.5 gpm 5.4 gpm Total Hydraulic Flow 22.4 gpm 14.8 gpm (9.4 + 5.4, computed) Overall Hydraulic Pump Flow 22.4 gpm 14.8 gpm (9.4 + 5.4, computed) Hydraulic System Type Open center Open center (two separate circuits) Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves 1 (third rear remote, DIA kit) 3 ▶ Fluid CapacityFuel Tank Capacity 23.8 gal Not Published Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully independent hydraulic Not Published PTO Rear 540 rpm 540/540E Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Not Published Hitch Lift Capacity Not Published 7,793 lb Hitch Lift Capacity (at 24”) 3,664 lb Not Published Lift Control Type Mechanical draft control; single-lever raise and lower (standard) Lift-O-Matic ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle, column-mounted (standard); 20x20 power shuttle with creeper (optional) 8x8 shuttle (16x8 creeper gearbox optional) No. of Speeds 12F/12R (standard); 20F/20R with creeper (optional) 8F/8R (16F/8R with creeper) Max Travel Speed (Forward) 27 mph (4WD front axle); 20 mph (2WD front axle) 6.8 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock (pedal); limited-slip 4WD front axle Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Steering-O-Matic (std); Steering-O-Matic Plus (opt) Brakes Wet disc Not Published Seat Suspension & Adjustability Air-suspension cloth seat with armrests, 10° swivel (cab, standard); full-size folding instructor seat Air suspension seat (optional) Front Axle Type 4WD limited-slip front axle, electrohydraulic engagement (standard); heavy-duty 2WD front axle (optional) Not Published Front Axle Rating 9,480 lb (standard 4WD front axle, maximum capacity); 7,716 lb (optional 2WD heavy-duty front axle) Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 75.6 in 55 in Wheelbase 85.8 in (2WD); 83.9 in (4WD) 52.8 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 134 in (2WD front axle) Not Published Height to Top of ROPS n/a (cab model) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 97.9 in Not Published Overall Length 152.9 in (2WD); 151.0 in (4WD) Not Published ▶ WeightTractor Weight (Base) 5,622 lb (2WD cab); 6,239 lb (4WD cab) Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD: 7.50-16 front, 16.9R30 rear; 4WD: 11.2R24 front, 16.9R30 rear (standard ag tires) SmartTrax rubber tracks, 43.3 in track width R1 Agricultural - Front 2WD: 7.50-16; 4WD: 11.2R24 Not Published R1 Agricultural - Rear 16.9R30 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style quick-attach faceplate; on PowerStar 75, 710LU and 715LU come only with the skid-steer-style faceplate Not Published Loader Model 710LU (NSL); 715LU (MSL) Not Published Loader Lift Height 710LU: 126.3 in; 715LU: 125.9 in Not Published Loader Lift Capacity (Full Height) 710LU: 3,461 lb; 715LU: 3,573 lb (at pivot pins) Not Published Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
