▶ EngineEngine Manufacturer FPT Industrial Deutz Engine Model F5C TCD2.9L4 Engine Type 4-cylinder diesel, turbocharged and aftercooled 4-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 4 4 Displacement 207 in³ 177 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 65 hp 64.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dual dry Fuel System Electronic high-pressure common rail fuel injection CRDI Alternator 120 A 95 A, 12 V ▶ HydraulicsPump Type Open-center; dual pumps (implement + dedicated steering) Dual gear pump Implement Flow 12.9 gpm 10.3 gpm Steering Flow 9.5 gpm 5.8 gpm Total Hydraulic Flow 22.4 gpm 16.1 gpm Overall Hydraulic Pump Flow 22.4 gpm 16.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 1 (third rear remote, DIA kit) Not Published ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 23.8 gal Coolant Capacity Not Published 10.6 qt Crankcase Capacity Not Published 8.5 qt Transmission / Hydraulic System Capacity Not Published 18 gal Front Axle Fluid Capacity Not Published 17.3 qt ▶ PTO & HitchPTO Type Fully independent hydraulic Independent PTO Rear 540 rpm 540/750 rpm; 540/1000 rpm (Opt) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 5,115 lb Hitch Lift Capacity (at 24”) 3,664 lb 3,418 lb Lift Control Type Mechanical draft control; single-lever raise and lower (standard) Position/Draft/Elec ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle, column-mounted (standard); 20x20 power shuttle with creeper (optional) Synchro-shuttle No. of Speeds 12F/12R (standard); 20F/20R with creeper (optional) F16 x R16 (Creep interlock) Max Travel Speed (Forward) 27 mph (4WD front axle); 20 mph (2WD front axle) 24.1 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published M: Dry Single Plate; PS: Wet Multi Plate Differential Lock & Limited Slip Options Mechanical rear differential lock (pedal); limited-slip 4WD front axle Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Brakes Wet disc Wet disc Seat Suspension & Adjustability Air-suspension cloth seat with armrests, 10° swivel (cab, standard); full-size folding instructor seat Suspension seat Front Axle Type 4WD limited-slip front axle, electrohydraulic engagement (standard); heavy-duty 2WD front axle (optional) MFWD (4WD) Front Axle Rating 9,480 lb (standard 4WD front axle, maximum capacity); 7,716 lb (optional 2WD heavy-duty front axle) Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 75.6 in 76.4 in Wheelbase 85.8 in (2WD); 83.9 in (4WD) 86.1 in Ground Clearance Not Published 18.3 in Min. Turn Radius without Brakes 134 in (2WD front axle) 162.8 in Height to Top of ROPS n/a (cab model) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 97.9 in 103.3 in Overall Length 152.9 in (2WD); 151.0 in (4WD) 155.7 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 5,622 lb (2WD cab); 6,239 lb (4WD cab) 6,052 lb (weight with cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 7,904 lb (6,052 + 1,852, computed) ▶ Tire OptionsTire Size & Options 2WD: 7.50-16 front, 16.9R30 rear; 4WD: 11.2R24 front, 16.9R30 rear (standard ag tires) R1 Agricultural, R4 Industrial R1 Agricultural - Front 2WD: 7.50-16; 4WD: 11.2R24 FSTR 280/85R24 TL (11R24) R1 Agricultural - Rear 16.9R30 FSTR 420/85R30 TL (16.9R30) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Trac Chief 15-19.5 NHS TL 6PR R4 Industrial - Rear Not Published Xtra Grip 18.4-24 NHS TL 8PR ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style quick-attach faceplate; on PowerStar 75, 710LU and 715LU come only with the skid-steer-style faceplate TX75SL: Quick attach mechanism Loader Model 710LU (NSL); 715LU (MSL) TX75SL Loader Lift Height 710LU: 126.3 in; 715LU: 125.9 in TX75SL: 133.8 in Loader Lift Capacity (Full Height) 710LU: 3,461 lb; 715LU: 3,573 lb (at pivot pins) TX75SL: 3,325 lb (at pivot pin) Loader Breakout Force Not Published TX75SL: 5,485 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months
