▶ EngineEngine Manufacturer FPT John Deere Engine Model F36 PowerTech 4045 (4.5L) PWL Engine Type 4-cylinder diesel, turbocharged and aftercooled 4-cylinder, turbocharged and aftercooled diesel, electronic fuel control No. of Cylinders 4 4 Displacement 219.7 in³ 276 in³ Rated Engine Speed 2300 rpm 2400 rpm Engine Power (Gross) 88.5 hp 90 hp PTO Power Not Published 76.7 hp Engine Emissions Constraints Stage V (ECOBlue Compact HI-eSCR + Light CEGR) Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Dry type with safety element Fuel System Common rail fuel injection High pressure common rail, electronic fuel control Alternator Not Published OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering pump Tandem gear pump, two engine-mounted pumps Implement Flow 21.7 gpm 15.9 gpm Steering Flow 9.7 gpm 6.6 gpm Total Hydraulic Flow 31.4 gpm (21.7 + 9.7, computed) 22.5 gpm Overall Hydraulic Pump Flow 31.4 gpm (21.7 + 9.7, computed) 22.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear remotes (four couplers) 2 rear; 0 mid No. of Optional Remote Valves 1 (3rd rear remote); 1 with diverter (3rd rear remote with 1 diverter) 3 rear; up to 3 mid ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 25 gal (open operator station); 30 gal (cab) Coolant Capacity Not Published 2.5 gal (open operator station); 3 gal (cab) Crankcase Capacity Not Published 3.2 gal Transmission / Hydraulic System Capacity Not Published 11.5 gal Front Axle Fluid Capacity Not Published 1.3 gal (MFWD differential housing); 0.74 qt (each wheel hub) ▶ PTO & HitchPTO Type Fully independent electrohydraulic PTO, wet clutch Independent, electro-hydraulic engagement, wet PTO clutch PTO Rear 540/1000 rpm (interchangeable, standard) 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category 2, convertible to Category 1 Hitch Lift Capacity Not Published 5,159 lb (maximum lift force at hitch ball); 3,846 lb throughout lift range Hitch Lift Capacity (at 24”) 4,123 lb 4,630 lb (electrohydraulic hitch) Lift Control Type Electronic draft control (Dual Command); single-lever Lift-O-Matic PLUS (standard) Electro-hydraulic hitch with electronic quick raise and lower (premium cab); top-link draft sensing ▶ Transmission & DrivetrainTransmission Type 24x24 Dual Command hi-lo power shuttle, column-mounted PowrReverser 12F/12R standard; PowrReverser Hi-Lo 24F/12R optional No. of Speeds 24F/24R (Dual Command) 12 forward, 12 reverse (standard); 24 forward, 12 reverse (Hi-Lo) Max Travel Speed (Forward) 25 mph 21.7 mph (electronically limited) Max Travel Speed (Reverse) Not Published 21.7 mph (electronically limited) Clutch Not Published Wet Differential Lock & Limited Slip Options Electrohydraulic rear differential lock Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Foldable ROPS (open operator station); standard or premium cab; MFWD Steering Not Published Hydrostatic power steering Brakes Not Published Hydraulic wet disc, self-equalizing and self-adjusting, dual-stage Seat Suspension & Adjustability Air-suspension cloth seat Mechanical seat standard; air-suspension seat optional for cab Front Axle Type Heavy-duty class 1.5 4WD front axle MFWD Front Axle Rating Not Published 6,615 lb Drawbar Capacity Not Published 2,755 lb (standard drawbar, 9.8 in extended); 2,425 lb (standard drawbar, 350 and 15.7 in extended); 3,195 lb (heavy-duty drawbar, 9.8 in extended); 2,645 lb (heavy-duty drawbar, 350 and 15.7 in extended) ▶ Dimensions & ManeuverabilityOverall Width 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) 83.6 in (minimum, 16.9-30 R1 tires); 85.1 in (minimum, 18.4-30 R1 tires) Wheelbase 92.5 in 92.5 in Ground Clearance Not Published 17 in (front axle) Min. Turn Radius without Brakes Not Published 11.6 ft (MFWD) Height to Top of ROPS Not Published 101.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.6 in 102.4 in Overall Length 158.2 in 159.13 in ▶ WeightTractor Weight (Base) 10,240 lb 7,275 lb (MFWD open operator station, shipping weight); 8,150 lb (MFWD cab, shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 420/85R38 (reference tire for weight and dimensions); rear tires as large as R38 available 18.4-30 R1 bias rear standard; 16.9-30 R1 also listed R1 Agricultural - Front Not Published 12.4-24 R1 Agricultural - Rear Not Published 18.4-30 R1 bias R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (available, both LU loaders) Quick attach option with integrated parking stand Loader Model 650LU (NSL); 655LU (MSL) 520M (NSL and MSL); 540M (NSL) Loader Lift Height 650LU: 149.7 in; 655LU: 149.7 in 520M MSL: 132.0 in Loader Lift Capacity (Full Height) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) 520M MSL: 2,606 lb (to maximum height, measured at pivot) Loader Breakout Force Not Published 520M NSL: 4,511 lbf; 520M MSL: 4,793 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Not Published Powertrain 5 years or 2,000 hours, as sold new
