▶ EngineEngine Manufacturer FPT John Deere Engine Model F36 John Deere PowerTech 4.5L diesel Engine Type 4-cylinder diesel, turbocharged and aftercooled 4-cylinder, turbocharged and intercooled diesel, 4-valve high pressure common rail No. of Cylinders 4 4 Displacement 219.7 in³ 276 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 88.5 hp 90 hp PTO Power Not Published 75 hp @ 100 rpm Engine Emissions Constraints Stage V (ECOBlue Compact HI-eSCR + Light CEGR) Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Dry type with safety element Fuel System Common rail fuel injection High pressure common rail, 4 valve, electronic fuel control Alternator Not Published 200 A ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering pump Tandem gear pump (open center); variable axial-piston implement pump (PFC, optional) Implement Flow 21.7 gpm 19.3 gpm (open center); 30.9 gpm (PFC) Steering Flow 9.7 gpm 6.3 gpm (open center) Total Hydraulic Flow 31.4 gpm (21.7 + 9.7, computed) 25.6 gpm (open center) Overall Hydraulic Pump Flow 31.4 gpm (21.7 + 9.7, computed) 25.6 gpm (open center); 30.9 gpm (PFC) Hydraulic System Type Open center Open center (standard); closed center PFC (optional) Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear remotes (four couplers) 2 rear and 2 mid (stackable) No. of Optional Remote Valves 1 (3rd rear remote); 1 with diverter (3rd rear remote with 1 diverter) Rear: 3 (mechanical or proportional EH, optional; 4th rear by conversion kit); Mid: 3 Deluxe (mechanical or EH, optional) ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 38 gal Coolant Capacity Not Published 4.25 gal Crankcase Capacity Not Published 3.1 gal Transmission / Hydraulic System Capacity Not Published 11.75 gal (open center); 12.5 gal (closed center PFC) Front Axle Fluid Capacity Not Published 1.3 gal (MFWD differential housing); 0.2 gal (each wheel hub) ▶ PTO & HitchPTO Type Fully independent electrohydraulic PTO, wet clutch Independent, electro-hydraulic engagement, wet PTO clutch, reversible 540/1000 shaft PTO Rear 540/1000 rpm (interchangeable, standard) 540/540E/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II (telescoping draft links with Category II balls) Hitch Lift Capacity Not Published 7,158 lb; 8,157 lb throughout lift range at hitch ball; 11,122 lb / 12,515 lb maximum Hitch Lift Capacity (at 24”) 4,123 lb 6,975 lb; 7,868 lb throughout lift range Lift Control Type Electronic draft control (Dual Command); single-lever Lift-O-Matic PLUS (standard) Electro-hydraulic hitch with fender controls, lower-link draft sensing ▶ Transmission & DrivetrainTransmission Type 24x24 Dual Command hi-lo power shuttle, column-mounted CommandQuad 16F/16R manual with electronic range and gear shifting, AutoClutch and wet traction clutch (standard); CommandQuad 16F/16R Auto, CommandQuad 16F/16R manual with creeper, or Command8 32F/16R (optional) No. of Speeds 24F/24R (Dual Command) 16F/16R (CommandQuad, standard); 32F/16R (Command8, optional) Max Travel Speed (Forward) 25 mph 22.0 mph (D4, 16/16 transmission, 480/70R28 rear tires) Max Travel Speed (Reverse) Not Published 18.6 mph Clutch Not Published Wet traction clutch with AutoClutch Differential Lock & Limited Slip Options Electrohydraulic rear differential lock Electro-hydraulic differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Cab standard with air conditioning; mechanical front-wheel drive (MFWD) Steering Not Published Hydrostatic power steering Brakes Not Published Hydraulic wet disc, self-equalizing and self-adjusting, lockable turning brakes; electronic park brake Seat Suspension & Adjustability Air-suspension cloth seat Not Published Front Axle Type Heavy-duty class 1.5 4WD front axle MFWD, electro-hydraulic engagement, planetary final drives Front Axle Rating Not Published 7,937 lb (MFWD closed center); 7,055 lb (MFWD open center) Drawbar Capacity Not Published 2,756 lb (standard drawbar, 9.8 in extended); 2,205 lb (standard, 13.8 in extended); 3,197 lb (heavy duty, 9.8 in extended); 2,646 lb (heavy duty, 13.8 in extended) ▶ Dimensions & ManeuverabilityOverall Width 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) 87 in (with fender extension); 74 in (without fender extension); 66.9 in (narrow cab, without fender extension) Wheelbase 92.5 in 88.6 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.6 in 106.1 in Overall Length 158.2 in 147.8 in ▶ WeightTractor Weight (Base) 10,240 lb 9,811 lb (base machine weight, with all fluids) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 420/85R38 (reference tire for weight and dimensions); rear tires as large as R38 available 320/85R24 (12.4R24) R1-W radial front and 460/85R30 (18.4R30) R1-W radial rear standard; optional 11.2R28/13.6R38, 380/70R20/480/70R28, 13.6R24/16.9R34, 380/70R24/480/70R34 R1; R3 44x18-20/23.1-26; R4 12.5/80-18/19.5L-24 R1 Agricultural - Front Not Published 320/85R24 (12.4R24) R1-W radial R1 Agricultural - Rear Not Published 460/85R30 (18.4R30) R1-W radial R3 Turf - Front Not Published 44x18-20 R3 Turf - Rear Not Published 23.1-26 R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (available, both LU loaders) Global carrier in base; John Deere 500-style carrier optional (540R) Loader Model 650LU (NSL); 655LU (MSL) 540R (non self-leveling and mechanical self-leveling) Loader Lift Height 650LU: 149.7 in; 655LU: 149.7 in 540R: 141.5 in Loader Lift Capacity (Full Height) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) 540R NSL: 4,246 lb (measured at pivot) Loader Breakout Force Not Published 540R NSL: 4,945 lbf (measured at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
