▶ EngineEngine Manufacturer FPT Industrial FPT Industrial Engine Model F5G S8000 Engine Type 4-cylinder diesel, turbocharged and aftercooled Turbocharged, intercooled 3-cylinder diesel No. of Cylinders 4 3 Displacement 207 in³ 179 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 86 hp 74 hp PTO Power 73 hp 60 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Not Published Not Published Fuel System Electronic high-pressure common rail fuel injection Common rail fuel injection Alternator ROPS: 120 A; Cab: 150 A Not Published ▶ HydraulicsPump Type Open-center; dual pumps (implement pump plus dedicated steering pump) Dual-pump Implement Flow 16.9 gpm 12.6 gpm Steering Flow 9.7 gpm 7.6 gpm Total Hydraulic Flow 26.6 gpm 20.2 gpm Overall Hydraulic Pump Flow 26.6 gpm 20.2 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear remotes (open center with detent) 2 No. of Optional Remote Valves 1 (third rear remote, DIA kit) 3 ▶ Fluid CapacityFuel Tank Capacity 30.3 gal Not Published Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully independent hydraulic PTO Not Published PTO Rear 540 rpm (standard); 540/1000 rpm with interchangeable shafts (optional) 540/540E Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Not Published Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 5,620 lb 4,000 lb Lift Control Type Mechanical draft control; Lift-O-Matic PLUS single-lever raise/lower (standard) Lift-O-Matic ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle, column-mounted (standard); 20x20 power shuttle with creeper (optional) 12x12 Mechanical Shuttle No. of Speeds 12F/12R (standard); 20F/20R with creeper (optional) 12F/12R Max Travel Speed (Forward) 27 mph (4WD front axle); 20 mph (2WD front axle) Not Published Max Travel Speed (Reverse) 27.25 mph (12x12, 4WD front axle, 18R34 tires) Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock (pedal); limited-slip 4WD front axle with electrohydraulic engagement Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Straddle-deck platform Steering Power steering Not Published Brakes Hydraulic wet disc Not Published Seat Suspension & Adjustability Cab: air-suspension cloth seat with armrests, 10° swivel (standard); ROPS: vinyl mechanical-suspension seat with armrests Vinyl suspension seat Front Axle Type Limited-slip 4WD front axle with electrohydraulic engagement (standard); heavy-duty 2WD front axle (optional) 4WD front axle, electronic engagement Front Axle Rating 9,480 lb (standard limited-slip 4WD front axle, maximum capacity); 10,360 lb (optional heavy-duty 4WD front axle); 7,716 lb (optional 2WD heavy-duty front axle) Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 163.1 in (2WD); 160.9 in (4WD) 143 in Overall Width 75.7 in 57 in Wheelbase 92.2 in (2WD); 89.9 in (4WD) 73 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 134 in (optional 2WD front axle, w/o brakes) Not Published Height to Top of ROPS 106.5 in 97 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102.1 in Not Published ▶ WeightTractor Weight (Base) 6,988 lb (ROPS/2WD); 7,672 lb (ROPS/4WD); 7,473 lb (cab/2WD); 8,157 lb (cab/4WD) 5,000 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD: 10.00-16 front, 18.4-30 rear; 4WD: 12.4-24 front, 18.4-30 rear (standard); 18.4R34 rear is the reference tire for weights and dimensions Not Published R1 Agricultural - Front 2WD: 10.00-16; 4WD: 12.4-24 Not Published R1 Agricultural - Rear 18.4R34 (reference tire for OEM weights and dimensions) 320/70R20 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (optional, all four LU loaders) Not Published Loader Model 710LU (NSL); 715LU (MSL); 720LU (NSL); 725LU (MSL) Not Published Loader Lift Height 710LU: 126.3 in; 715LU: 125.9 in; 720LU: 134 in; 725LU: 135 in Not Published Loader Lift Capacity (Full Height) 710LU: 3,461 lb; 715LU: 3,573 lb; 720LU: 3,849 lb; 725LU: 4,204 lb Not Published Loader Breakout Force 710LU: 3,739 lb; 715LU: 3,860 lb; 720LU: 4,455 lb; 725LU: 5,661 lb (31.5 in forward of the bucket pivot point) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
