▶ EngineEngine Manufacturer FPT FPT Industrial Engine Model F36 F5G Engine Type 4-cylinder diesel, turbocharged and aftercooled 4-cylinder diesel No. of Cylinders 4 4 Displacement 219.7 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 88.5 hp 86 hp PTO Power Not Published 73 hp Engine Emissions Constraints Stage V (ECOBlue Compact HI-eSCR + Light CEGR) Tier 4B Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Not Published Fuel System Common rail fuel injection Electronic high-pressure common rail fuel injection Alternator Not Published Not Published ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering pump Open-center tandem gear pumps: implement pump plus steering and services pump Implement Flow 21.7 gpm 16.9 gpm Steering Flow 9.7 gpm 9.7 gpm Total Hydraulic Flow 31.4 gpm (21.7 + 9.7, computed) 26.6 gpm Overall Hydraulic Pump Flow 31.4 gpm (21.7 + 9.7, computed) 26.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear remotes (four couplers) 2 or 3 (base) No. of Optional Remote Valves 1 (3rd rear remote); 1 with diverter (3rd rear remote with 1 diverter) Third rear remote (dealer-installed) ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 30.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully independent electrohydraulic PTO, wet clutch Hydraulic PTO with power shuttle transmissions; lever-engaged PTO with mechanical shuttle PTO Rear 540/1000 rpm (interchangeable, standard) 540 (12x12 base); 540/540E or 540/1000 (12x12 optional); 540/540E (24x24 Dual Command base); 540/1000 (24x24 Dual Command optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II (flexible link ends) Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,123 lb 5,620 lb (7,351 lb with optional auxiliary lift ram) Lift Control Type Electronic draft control (Dual Command); single-lever Lift-O-Matic PLUS (standard) 12x12: rear hitch control levers; Dual Command cab: Electronic Draft Control (EDC) mouse and fender switches; single-lever Lift-O-Matic Plus (optional on 12x12, standard on Dual Command ROPS) ▶ Transmission & DrivetrainTransmission Type 24x24 Dual Command hi-lo power shuttle, column-mounted 12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command Hi-Lo powershift with electrohydraulic power shuttle, or 40x40 Dual Command with creeper (optional) No. of Speeds 24F/24R (Dual Command) 12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional) Max Travel Speed (Forward) 25 mph 20 mph (12x12 and 20x20 creeper, standard; 25 mph transport option); 25 mph (24x24 and 40x40 Dual Command) Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Electrohydraulic rear differential lock Mechanical rear differential lock, pedal (12x12 models); electrohydraulic rear differential lock, rocker switch (Dual Command models) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Power steering Brakes Not Published Wet disc Seat Suspension & Adjustability Air-suspension cloth seat Cab: fabric mechanical-suspension seat or fabric air-suspension seat with swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests Front Axle Type Heavy-duty class 1.5 4WD front axle Standard-duty, electronically engaged 4WD front axle (standard); optional: mechanically engaged standard-duty 4WD, electronically engaged heavy-duty 4WD, or heavy-duty 2WD front axle Front Axle Rating Not Published 9,479 lb (standard-duty 4WD, in-action capacity at 4 mph); 10,361 lb (heavy-duty 4WD, in-action capacity at 4 mph) Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) 75.7 in Wheelbase 92.5 in 92.2 in (2WD); 89.9 in (4WD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 134 in (2WD heavy-duty front axle) Height to Top of ROPS Not Published 106.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.6 in 102.1 in Overall Length 158.2 in 163.1 in (2WD); 160.9 in (4WD) ▶ WeightTractor Weight (Base) 10,240 lb 6,988 lb (2WD ROPS); 7,672 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 420/85R38 (reference tire for weight and dimensions); rear tires as large as R38 available Ag: 11.2-24 front, 16.9-30 rear; 13.6-24 front, 16.9-34 rear; 12.4-24 front, 18.4-30 rear; 14.9-24 front, 18.4-34 rear; Turf: 13.6-16.1 front, 16.9-24 rear; Industrial: 12.5/80-18 front, 19.5L24 rear R1 Agricultural - Front Not Published 4WD: 11.2-24, 13.6-24, 12.4-24 or 14.9-24 (paired with 16.9-30, 16.9-34, 18.4-30 or 18.4-34 rears) R1 Agricultural - Rear Not Published 16.9-30, 16.9-34, 18.4-30 or 18.4-34 R3 Turf - Front Not Published 13.6-16.1 R3 Turf - Rear Not Published 16.9-24 R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L24 ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (available, both LU loaders) Skid-steer-style or Euro-style quick attach faceplate Loader Model 650LU (NSL); 655LU (MSL) Factory-fit: 655TL (NSL or MSL), 665TL (NSL or MSL); field-fit: 632TL (NSL), 637TL (MSL) Loader Lift Height 650LU: 149.7 in; 655LU: 149.7 in 655TL NSL: 126 in; 655TL MSL: 125 in; 665TL NSL: 134 in; 665TL MSL: 135 in; 632TL: 134 in; 637TL: 134 in Loader Lift Capacity (Full Height) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 665TL NSL: 2,632 lb; 665TL MSL: 3,428 lb (at 31.5 in from pivot point); 632TL: 2,028 lb; 637TL: 3,175 lb (to max height, 31.5 in from pivot point) Loader Breakout Force Not Published 655TL NSL: 3,739 lb; 655TL MSL: 3,860 lb; 665TL NSL: 4,455 lb; 665TL MSL: 5,661 lb (at 31.5 in from bucket pivot point); 632TL: 3,351 lb; 637TL: 3,461 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
