▶ EngineEngine Manufacturer FPT FPT Engine Model F36 F36 Engine Type 4-cylinder diesel, turbocharged and aftercooled 4-cylinder No. of Cylinders 4 4 Displacement 219.7 in³ Not Published Rated Engine Speed 2300 rpm Not Published Engine Power (Gross) 88.5 hp 101 hp PTO Power Not Published 85 hp Engine Emissions Constraints Stage V (ECOBlue Compact HI-eSCR + Light CEGR) Not Published Cooling System Type Not Published Not Published Air Cleaner Not Published Not Published Fuel System Common rail fuel injection Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering pump Not Published Implement Flow 21.7 gpm Not Published Steering Flow 9.7 gpm Not Published Total Hydraulic Flow 31.4 gpm (21.7 + 9.7, computed) 26.6 gpm Overall Hydraulic Pump Flow 31.4 gpm (21.7 + 9.7, computed) Not Published Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear remotes (four couplers) Not Published No. of Optional Remote Valves 1 (3rd rear remote); 1 with diverter (3rd rear remote with 1 diverter) Not Published ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 34.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully independent electrohydraulic PTO, wet clutch Not Published PTO Rear 540/1000 rpm (interchangeable, standard) Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Not Published Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,123 lb Not Published Lift Control Type Electronic draft control (Dual Command); single-lever Lift-O-Matic PLUS (standard) Not Published ▶ Transmission & DrivetrainTransmission Type 24x24 Dual Command hi-lo power shuttle, column-mounted 12x12 electronic power shuttle No. of Speeds 24F/24R (Dual Command) 12 forward / 12 reverse Max Travel Speed (Forward) 25 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Electrohydraulic rear differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Not Published Brakes Not Published Not Published Seat Suspension & Adjustability Air-suspension cloth seat Air ride seat (standard); instructor seat available Front Axle Type Heavy-duty class 1.5 4WD front axle Class 1.0 HD heavy-duty front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) Not Published Wheelbase 92.5 in Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.6 in Not Published Overall Length 158.2 in Not Published ▶ WeightTractor Weight (Base) 10,240 lb Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 420/85R38 (reference tire for weight and dimensions); rear tires as large as R38 available Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (available, both LU loaders) Not Published Loader Model 650LU (NSL); 655LU (MSL) 630LU; 635LU Loader Lift Height 650LU: 149.7 in; 655LU: 149.7 in 143.9 in (630LU and 635LU) Loader Lift Capacity (Full Height) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) 630LU: 2,764 lb; 635LU: 3,882 lb (at max height, @ 31.5 in) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
