▶ EngineEngine Manufacturer FPT FPT Industrial Engine Model F5C F5C Engine Type 4-cylinder diesel, turbocharged 4-cylinder diesel, turbocharged and aftercooled No. of Cylinders 4 4 Displacement 207 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 65 hp 65 hp Engine Emissions Constraints US EPA Tier 4B Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Not Published Fuel System Common rail fuel injection Electronic high-pressure common rail fuel injection Alternator 120 A 120 A ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering and services pump Open-center; dual pumps (implement + dedicated steering) Implement Flow 12.5 gpm 12.9 gpm Steering Flow 7.3 gpm (mechanical shuttle); 9.5 gpm (power shuttle) 9.5 gpm Total Hydraulic Flow 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) 22.4 gpm Overall Hydraulic Pump Flow 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) 22.4 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Up to 3 rear remotes 1 (third rear remote, DIA kit) ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 23.8 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully independent Fully independent hydraulic PTO Rear 540 rpm at 1,958 engine rpm (standard); 540E at 1,592 engine rpm (optional) 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II / I Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,664 lb 3,664 lb Lift Control Type Mechanical draft control; top link draft sensing Mechanical draft control; single-lever raise and lower (standard) ▶ Transmission & DrivetrainTransmission Type 8x8 mechanical synchro shuttle (standard); 8x8 hydraulic power shuttle, 12x12 mechanical synchro shuttle or 12x12 hydraulic power shuttle (optional); creeper available with the power shuttle transmissions 12x12 power shuttle, column-mounted (standard); 20x20 power shuttle with creeper (optional) No. of Speeds 8F/8R (standard); 12F/12R (optional); 12F/12R or 20F/20R with creeper (optional) 12F/12R (standard); 20F/20R with creeper (optional) Max Travel Speed (Forward) 20.1 mph (8x8 and 12x12, 20 mph transmissions); 24.1 mph (optional 24 mph 12x12 transmission, 4WD only) 27 mph (4WD front axle); 20 mph (2WD front axle) Max Travel Speed (Reverse) 20.1 mph Not Published Clutch Mechanical dry disc (mechanical shuttle); wet disc (power shuttle) Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical rear differential lock (pedal); limited-slip 4WD front axle ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulic wet disc Wet disc Seat Suspension & Adjustability Optional deluxe air suspension seat with fully integrated armrest and 10° swivel to the right; full-size instructor seat with seatbelt Air-suspension cloth seat with armrests, 10° swivel (cab, standard); full-size folding instructor seat Front Axle Type Heavy-duty 2WD front axle; electronic 4WD front axle (optional) 4WD limited-slip front axle, electrohydraulic engagement (standard); heavy-duty 2WD front axle (optional) Front Axle Rating Not Published 9,480 lb (standard 4WD front axle, maximum capacity); 7,716 lb (optional 2WD heavy-duty front axle) Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 75.6 in Wheelbase 85.8 in (2WD); 83.9 in (4WD) 85.8 in (2WD); 83.9 in (4WD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 134 in (2WD front axle) 134 in (2WD front axle) Height to Top of ROPS Not Published n/a (cab model) Height to Top of ROPS (folded) 76 to 78.9 in Not Published Height to Top of Cab Model 94.8 to 97.8 in 97.9 in Overall Length 151 in 152.9 in (2WD); 151.0 in (4WD) ▶ WeightTractor Weight (Base) 5,027 lb (2WD ROPS); 5,952 lb (4WD ROPS) 5,622 lb (2WD cab); 6,239 lb (4WD cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 2WD: 7.50-16 front, 16.9R30 rear; 4WD: 11.2R24 front, 16.9R30 rear (standard ag tires) R1 Agricultural - Front Not Published 2WD: 7.50-16; 4WD: 11.2R24 R1 Agricultural - Rear Not Published 16.9R30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate Skid-steer-style quick-attach faceplate; on PowerStar 75, 710LU and 715LU come only with the skid-steer-style faceplate Loader Model Factory-fit: 655TL (NSL or MSL); field-fit: 622TL (NSL), 627TL (MSL) 710LU (NSL); 715LU (MSL) Loader Lift Height 655TL NSL: 126 in; 655TL MSL: 125 in; 622TL: 121 in; 627TL: 121 in 710LU: 126.3 in; 715LU: 125.9 in Loader Lift Capacity (Full Height) 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 622TL: 1,830 lb; 627TL: 2,557 lb (to max height, at 31.5 in from pivot point) 710LU: 3,461 lb; 715LU: 3,573 lb (at pivot pins) Loader Breakout Force 655TL NSL: 3,739 lb; 655TL MSL: 4,665 lb; 622TL: 3,042 lb; 627TL: 3,307 lb Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
