▶ EngineEngine Manufacturer FPT Industrial Deutz Engine Model F34 TCD2.9 L4 Engine Type 4-cylinder diesel, Smart Wastegate Turbo, intercooled Turbocharged No. of Cylinders 4 4 Displacement 207 in³ 177.0 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 65 hp 64.1 hp Engine Emissions Constraints Tier 4B Final Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Common-rail fuel injection Common Rail Direct Injection Alternator Not Published 95 A, 12 V ▶ HydraulicsPump Type Dual-pump, open center Not Published Implement Flow 16.9 gpm (standard); 21.1 gpm (optional, cab) 10.3 gpm Steering Flow 9.2 gpm 5.8 gpm Total Hydraulic Flow 26.1 gpm (16.9 + 9.2, computed); 30.3 gpm with optional cab implement pump (21.1 + 9.2, computed) 16.1 gpm Overall Hydraulic Pump Flow 26.1 gpm (16.9 + 9.2, computed); 30.3 gpm with optional cab implement pump (21.1 + 9.2, computed) 16.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves ROPS: 3+2 (10 outlets); CAB: 4 (8 outlets) Not Published ▶ Fluid CapacityFuel Tank Capacity ROPS: 21.4 gal; CAB: 27.5 gal 23.8 gal Coolant Capacity Not Published 10.6 qt Crankcase Capacity Not Published 8.5 qt Transmission / Hydraulic System Capacity Not Published 18.0 gal Front Axle Fluid Capacity Not Published 17.4 qt ▶ PTO & HitchPTO Type Electrohydraulic wet clutch (std on cab; opt on ROPS) Independent PTO Rear 540/540E (std); 540/540E/1000 and ground speed (opt) 540/750 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch Not Published Category II Hitch Lift Capacity 5,553 lb 5,115 lb Hitch Lift Capacity (at 24”) Not Published 3,414 lb Lift Control Type Mechanical draft control with Lift-O-Matic system (standard); electronic draft control (optional, cab) Position / Draft / Mechanical ▶ Transmission & DrivetrainTransmission Type ROPS: 16x16 Shuttle Command, 32x16 Dual Command; CAB: 16x16 Power Shuttle, 32x16 Dual Command RK74 Power Shuttle Cab (RK74PSC): 16F/16R power shuttle with creeper; RK74 Shuttle Shift Cab: 16F/16R synchronized shuttle with creeper No. of Speeds 16F/16R; 32F/16R 16 forward, 16 reverse (creeper interlock) Max Travel Speed (Forward) 25 mph 18.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Wet clutch Single plate dry clutch (11.81 in diameter); hydraulic clutch assembly for Independent PTO models Differential Lock & Limited Slip Options Electro-hydraulic differential lock 4WD, differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Steering Not Published Hydrostatic power steering Brakes Oil-immersed brakes Wet disc Seat Suspension & Adjustability Not Published High-back suspension seat with extension Front Axle Type 4WD front axle Center-pivot, reverse Eliot type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 54.3 in 76.4 in Wheelbase 85.8 in 86.1 in Ground Clearance Not Published 18.3 in Min. Turn Radius without Brakes Not Published 162.8 in Height to Top of ROPS 95.0 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 103.3 in Overall Length Not Published 157.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) Not Published 6,052 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 320/85R28 (T4F), 360/70R24 (T4F low-profile); other rear tires available Titan (USA): R4 Industrial (Std), R3 Turf (Opt), R1 Agricultural (Opt) R1 Agricultural - Front Not Published 11.2-24 R1 Agricultural - Rear Not Published 16.9-30 R3 Turf - Front Not Published 12.0-20.5 R3 Turf - Rear Not Published 22.4-25.5 R4 Industrial - Front Not Published 15-19.5 R4 Industrial - Rear Not Published 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published L135SL: Skid-steer compatible quick coupler, self-leveling Loader Model Not Published L135SL Loader Lift Height Not Published L135SL: 135.5 in Loader Lift Capacity (Full Height) Not Published L135SL: 3,223 lb at pivot pin to full height Loader Breakout Force Not Published L135SL: 5,335 lb at pivot pin ▶ WarrantyWarranty Length & Coverage Not Published Government and non-institutional: basic 24 months or 2,000 hours, powertrain 60 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
