▶ EngineEngine Manufacturer FPT Doosan Engine Model F5D DL03-LEA07 Engine Type 4-cylinder diesel 4-cylinder, in-line vertical, water-cooled diesel No. of Cylinders 4 4 Displacement 207 in³ 208 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 106 hp 110 hp PTO Power 91 hp 92.2 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Dual air cleaner Fuel System Not Published Not Published Alternator 120 A Not Published ▶ HydraulicsPump Type Gear pumps Gear Implement Flow T5.105: 16.1 gpm (21.1 gpm optional); T5.105 Electro Command: 21.1 gpm (16.1 gpm optional) Not Published Steering Flow T5.105: 10.0 gpm (11.4 gpm optional); T5.105 Electro Command: 11.4 gpm (10.0 gpm optional) Not Published Total Hydraulic Flow T5.105: 26.1 gpm (16.1 + 10.0, computed); T5.105 Electro Command: 32.5 gpm (21.1 + 11.4, computed) 31.5 gpm Overall Hydraulic Pump Flow T5.105: 26.1 gpm (16.1 + 10.0, computed); T5.105 Electro Command: 32.5 gpm (21.1 + 11.4, computed) 31.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (3 optional) 2 No. of Optional Remote Valves Not Published 1 (third valve) ▶ Fluid CapacityFuel Tank Capacity 37 gal 34.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic clutch Independent PTO Rear 540/1000 540 / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) T5.105: 6,393 lb (10,452 lb with 2 optional rams); T5.105 Electro Command: 6,393 lb (8,809 lb with 1 optional ram, 10,452 lb with 2) 8,002 lb Lift Control Type Electronic draft control Position, draft, mixed control ▶ Transmission & DrivetrainTransmission Type T5.105: 12x12 power shuttle (standard), 20x20 power shuttle with creeper or 24x24 Dual Command power shuttle (optional); T5.105 Electro Command: 16x16 power shuttle (standard), 32x32 power shuttle with creeper (optional) Synchronized shuttle, power shuttle type No. of Speeds T5.105: 12F/12R (20F/20R or 24F/24R optional); T5.105 Electro Command: 16F/16R (32F/32R optional) 32F/32R Max Travel Speed (Forward) Not Published 24.87 mph Max Travel Speed (Reverse) Not Published 24.69 mph Clutch Not Published Wet multi disc Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock; limited slip front Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulic wet disc Wet disc Seat Suspension & Adjustability Numerous seat options including a premium low-frequency heated air-suspension seat; full-size instructor seat available Fully adjustable suspension swivel seat (deluxe cab) Front Axle Type Heavy-duty 4WD front axle (standard) 4WD, electric/hydraulic engagement Front Axle Rating 4,500 lb (in-action capacity at 4 mph) Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch T5.105: 163.8 in; T5.105 Electro Command: 165.0 in 168.9 in Overall Width 82.6 in 88.6 in Wheelbase 92.5 in 93.3 in Ground Clearance Not Published 19.5 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model T5.105: 105.4 in; T5.105 Electro Command: 105.6 in (non-suspended cab), 107.2 in (suspended cab) 109 in ▶ WeightTractor Weight (Base) T5.105: 9,370 lb; T5.105 Electro Command: 9,700 lb 9,064 lb (with cab and ag tires; cab is standard) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural: 13.6-24 front, 18.4-34 rear R1 Agricultural - Front Not Published 13.6-24 R1 Agricultural - Rear Not Published 18.4-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or European-style Quick attach (QA) bucket, 90 in; dual lever quick attach, built-in parking stand Loader Model 825TL; 835TL (each NSL or MSL) KL1153 Loader Lift Height 825TL: 138 in; 835TL: 146 in KL1153: 143.3 in Loader Lift Capacity (Full Height) 825TL NSL: 2,843 lb; 825TL MSL: 2,954 lb; 835TL NSL: 3,483 lb; 835TL MSL: 3,681 lb KL1153: 4,190 lb Loader Breakout Force 825TL NSL: 2,976 lb; 825TL MSL: 3,284 lb; 835TL NSL: 3,725 lb; 835TL MSL: 4,100 lb KL1153: 8,310 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
